13 GKR-2011 IVUS Hardware Operator’s Guide
45975 Nokes Boulevard
Suite 115
Sterling, Virginia 20166
(703) 673-3320
www.gatekeepersecurity.com R8-02092019
GKR-1086
The GKR-1086 (Pole) (page 19) is the backbone for the various components of
the GKR-2011 IVUS System. The GKR-7067, GKR-7080, and the GKR-7043 are
attached to the Pole. The GKR-1086 itself is bolted to the ground near the GKR-
1043-2 and stands 6 feet tall.
GKR-1035
The GKR-1035 (Operator Terminal) (page 19) contains the software needed to
successfully operate the GKR-2011 IVUS System. The GKR-1035 is the primary
means of input and output for the GKR-2011 IVUS System. It displays the
imagery from the cameras as well as other data that may be collected during
the operation of the system. The operator can input any necessary data. The
terminal itself uses a touch screen monitor which can replace the keyboard and
mouse if desired.
