DEFINITIONS
GKR-1020 (Dual-View Scanner) – Captures imagery from the under carriage of a given
vehicle. Dual-View technology enables the IVUS software to capture imagery from
multiple angles.
GKR-1022-R (LED Light Rail) – Provides the necessary light to scan the underside of
the vehicle.
GKR-7043 (Control Box) – Central termination point for all components of the GKR-
2011.
GKR – 1035 (Operator Terminal) – The component of the Gatekeeper system which
runs the AUVIS™ software, displays the images from the various cameras, and allows
the operator to input data into the system.
GKR-1043 (Embedded Frame Assembly) – Installed into the ground at the lane. Holds
the GKR-1020 and the GKR-1022-R
GKR-1072 (CPU Cat 6 Cable) – Connects the Operator Terminal to the GKR-7043.
GKR-1075-R (Dual-View Scanner Cable) – Connects the Dual-View Scanner to the
GKR-7043.
GKR-1077-R (Light Rail Cable) – Connects the LED Light Rails to the GKR-7043.
GKR-1086 (Pole) – The backbone that supports the GKR-7067, GKR-7080, and the GKR-
7043. Additionally, the GKR-1088 can be supported if a part of the system.
GKR-1088 (Intelligent Vehicle Occupant Detector)– Captures imagery of the driver
and occupants of a given vehicle.
GKR-2011 (IVUS-Embedded) – The embedded intelligent optical system that scans the
underside of a vehicle and provides an overview image.
GKR-2021 (Auto Wash System) – Provides washing capabilities to the Scanner on a
scheduled basis.
GKR-6051-1 (Ground Loop Cable) – The triggering mechanism for the GKR-2011.
Installed into the ground near the GKR-1043-2 and terminates at the GKR-7043.
