8 GKR-2011 IVUS Hardware Operator’s Guide
45975 Nokes Boulevard
Suite 115
Sterling, Virginia 20166
(703) 673-3320
www.gatekeepersecurity.com R8-02092019
STANDARD COMPONENTS
The GKR-2011 IVUS System is composed of several standard components. Each of
which are listed below.
• GKR-1043
• GKR-1020
• GKR-1022-R
• GKR-7067
• GKR-7080
• GKR-7043
• GKR-2011-Cable Kit
• GKR-1086
• GKR-1035
GKR-1043
The GKR-1043 (Embedded Frame Assembly) (page 19) houses both the GKR-
1020 and the GKR-1022-Rs. This component is made of high strength steel
capable of supporting up to 10 US tons (10,000 KG). The embedded frame is
placed into a steel vault in the lanes where the GKR-2011 will be used.
GKR-1020
