MC2000 USER GUIDE
15
4. 2 – SPARE PARTS:
Note: Any intervention by the operator on the machine during the warranty period will render
it void.
To order any spare parts, it is necessary to give the part’s reference number, its computer code,
as well as the quantity required.
Example :
Reference : Piston
Computer Code : MC2000-8939
Quantity : 1
4. 2. 1 – MACHINE SPARE PARTS
Item Reference Description P/N Quantity
Item 6 / Fig 2 /Pge 6 MC2000-8937 Crimper Head 7482-19830 1
Item 3 / Fig 2 /Pge 6 MC2000-9356 Flange 7482-19831 1
Item 12 /Fig 2/Pge 6 MC2000-1104 Clamp screw CHC M10x45 12-9 7482-19832 16
Item 8 / Fig 2 /Pge 6 MC2000-8939 Piston 7482-19833 1
Item 4 / Fig 2 /Pge 6 MC2000-8940 Die holder 7482-19834 8
Item 13/ Fig 2/Pge 6 MC2000-8941 Stop Strip 7482-19835 1
Item 5 / Fig 2 /Pge 6 MC2000-8942 Return spring 7482-19836 8
Item 12 /Fig 4/Pge 9 MC2000-9120 Die holder spring 7482-19837 8
Item 17 /Fig 2/Pge 6 MC2000-9084 Carrying piston ring 7482-19838 1
Item 16 /Fig 2/Pge 6 MC2000-9088 Anti extrusion bush D 185 7482-19839 1
Item 16 /Fig 2/Pge 6 MC2000-9085 O-ring D 164.45 x 5.33 7482-19840 1
Item 15 /Fig 2/Pge 6 MC2000-9086 O-ring D 139.07 x 5.33 7482-19841 1
Item 15 /Fig 2/Pge 6 MC2000-9089 Anti extrusion bush D 140 7482-19842 1
Item 6 / Fig 4/ Pge 9 MC2000-211 Battery 9V 7482-19843 1
Item 6 / Fig 4 /Pge 9 MC2000-9091 Battery casing 7482-19844 1
Item 5 / Fig 4 /Pge 9 MC2000-9093 Push button 7482-19845 1
Item 7 / Fig 4/ Pge 9 MC2000-9094 Indicator light 7482-19846 1
Item 7 / Fig 4 /Pge 9 MC2000-9095 Indicator light bulb 7482-19847 1
Item 2 / Fig 4 /Pge 9 MC2000-8557 Manual pump 7482-19848 1
Item 13 /Fig 4/ Pge 9 MC2000-9083 Frame handle 7482-19849 2
Item 18/ Fig 2 /Pge 6 MC2000-9496 Gauge assembly 7482-19850 1
Item 2 /Fig 2 / Pge 6 MC2000-8943 Gauge rod 7482-19851 1
Item 11/Fig 2 /Pge 6 MC5000-4855 Die holder spring 7482-19230 8
Item 1/ Fig 2 / Pge 6 MC5000-21 Rev counter button 7482-19228 1
Item 9 / Fig 2/ Pge 6 MC5000-75 Micro switch 7482-19265 1
Item 10 /Fig 2/Pge 6 MC5000-54 Die retaining pins 7482-19033 8
4. 2. 2 – TOOLING SPARE PARTS
Item 7 /Fig 2/Pge 6 Crimping die sets (See Crimp Data CD for Product Numbers_ 8
