MODEL: Gateway FPD 1500 DATE: 1998 . 9. 20.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION REMARK
X201 6202TST001B CRYSTAL, SX-1 SUNNY ,SMD, 4.0MHZ ,30PPM, 18PF, TP
CN302 366-184F WAFER, 53015-0710 MOLEX 2.0mm R/A
CN303 366-184D WAFER, 53015-0510 MOLEX 2.0mm R/A
CN304 366-183D WAFER, 53014-0510 MOLEX 2.0mm S/T
LD301 0DL571300AA LED, SPR571MVW3 TP ROHM GREEN/RED 10,10MCD
R301 0RD1801Q609 RESISTOR, FIXED CARBON FILM, 1.80K 1/4W(3 5% TA52
R302 0RD4700Q609 RESISTOR, FIXED CARBON FILM, 470 OHM 1/4 W (3.4) 5%
R303 0RD1001Q609 RESISTOR, FIXED CARBON FILM, 1K 1/4W(3 5% TA52
S301 140-058E SWITCH, TACT, SKHV10910B LGEC NON 12V 20A HORIZENTAL
S302 140-058E SWITCH, TACT, SKHV10910B LGEC NON 12V 20A HORIZENTAL
S303 140-058E SWITCH, TACT, SKHV10910B LGEC NON 12V 20A HORIZENTAL
ZD301 0DZ560009CE DIODE, ZENER, MTZJ5.6B TP ROHM-K DO34 500MW 5.6V 5MA
J101 6612TAH002A JACK,AC/DC POWER, DC-001 UNITOP DC-001 2.0MM (UNITOP)
J102 6602T25007A WAFER, GC250-3P-LS-SO LGC 2.5mm R/A
J603 6602T20007A WAFER, 87264-2050 MOLEX 2.0MM BOARD
J604 6630TGA002A CONNECTOR (CIRC), D-SUB, 10220-55F3JL 3M 20PIN 1.27MM
LCD 6304TLT151B LCD, LGE TFT LCD LM151X1-G 15.1” 1024X768
ADAPTER 6634TBZ004A ADAPTER,AC-DC, PSCV450106A SAMSUNG 100V 24V 1.875A
INVERTER 6633TZA003A INVERTER ASSY, SAMSUNG LG1501 FOR 15.1” LCD MNT
or INVERTER 6633TZA001A INVERTER ASSY, AMBIT REV.1, (UO4.32.C.00) LCD
P/CORD 174-206F POWER CORD, UL/CSA 1830MM WALL IVORY
or P/CORD 174-240A & 174-240A POWER CORD, WALL OUT, 6FT, BK, FOR JAPAN ONLY
S/CABLE 6866TDM001A SIGNAL CABLE, UL20276 DT 2000MM COOL GRAY 3C
M-INVERTER 6631T10001C CONNECTOR ASSY, 10P H-H 130MM UL 1571 28
M-MODULE 6631T11006C CONNECTOR ASSY, 21P H-H 220MM UL20276SB10P+2C
M-CTRL 6631T20005E CONNECTOR ASSY, 7P H-H 60MM UL1061 AWG 26 TW
C- POWER 6631T20005B CONNECTOR ASSY, 5P,H-H,L60,UL1061 26
- 20 -
MISCELLANEOUS
CONTROL BOARD
INTERFACE BOARD
OTHERs
