Gateway FPD 1500 User Manual

1. LCD CHARACTERISTICS
Type : Color Active Matrix TFT LCD
Size : 15.1inch (38.35cm)
Pixel Pitch : 0.3mm x 0.3mm
Pixel Format : 1024 x 768 pixels (XGA)
RGB Stripe Arrangement
Color Depth : 8-bit, 16 million colors
Active Video Area : 307mm x 230mm
Surface Treatment : Anti-Glare, Hard Coating (3H)
Backlight Unit : Two-CCFL (Cold Cathode
Fluorescent Lamp)
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio
≥ 10
Left : 60° typ., 55° min.
Right : 60° typ., 55° min.
Top : 45° typ., 40° min.
Bottom : 45° typ., 40° min.
2-2. Luminance : 200 cd/m
2
typ.
2-3. Angle at Half Luminance
Left : 50° min.
Right : 50° min.
Top : 40° min.
Bottom : 30° min.
2-4. Contrast Ratio : 250:1 typical
3. SIGNAL (Refer to the Timing Chart)
3-1. Type : TMDS Digital
3-2. Voltage Level : 3.3V
3-3. Input Impedance : 50Ω
3-4. Operating Frequency
Horizontal : 48.363kHz
Vertical : 60Hz
4. POWER SUPPLY
4-1. Power Adaptor
Input : AC 100~240V, 50/60Hz 1.2A
Output : DC 24V 1.9A
4-2. Power Consumption
5. ENVIRONMENT
5-1. Operating Temperature: 10°C~35°C (50°F~95°F)
(Ambient)
5-2. Relative Humidity : 10%~80%
(Non-condensing)
5-3. Altitude : 0~10,000ft (3,030m)
6. DIMENSIONS (with TILT/SWIVEL)
Width : 389.2mm (15.32'')
Depth : 182.4mm (7.18'')
Height : 361.6mm (14.24'')
7. WEIGHT (with TILT/SWIVEL)
Net. Weight : 5.3kg (11.68 lbs)
Gross Weight : 7.2kg (15.87 lbs)
SPECIFICATIONS ................................................... 2
PRECAUTIONS ....................................................... 3
TIMING CHART ....................................................... 4
OPERATING INSTRUCTIONS ................................ 4
WIRING DIAGRAM ................................................. 5
DISASSEMBLY ....................................................... 6
BLOCK DIAGRAM ................................................... 8
TROUBLE SHOOTING GUIDE ............................... 9
PRINTED CIRCUIT BOARD................................... 12
EXPLODED VIEW...................................................14
REPLACEMENT PARTS LIST ...............................17
PIN CONFIGURATION............................................21
PACKING AND ACCESSORIES .............................27
SCHEMATIC DIAGRAM..........................................28
- 2 -
CONTENTS
MODE
POWER ON (NORMAL)
DPM
POWER OFF
SIGNAL
ON
OFF
-
POWER CONSUMPTION
less than 30 W
less than 5 W
less than 5 W
LED COLOR
GREEN
ORANGE
OFF
VIDEO
ACTIVE
OFF
-
SPECIFICATIONS
-
+

Gateway FPD 1500 Specifications

General

Brand	Gateway
Model	FPD 1500
Category	Monitor
Language	English
