Gateway FPD 1500 - Page 25

PARTSTYPE
PARTSTYPE
KDS181
MBRS190T3
12
3
- 26 -
KA78M05R
KA78M12R
1. INPUT
2. GND
3. OUTPUT
1. CATHODE 1
2. CATHODE 2
3. ANODE
1
3
2
1
3
2
KSC1623
1. BASE
2. EMITTER
3. COLLECTOR
2
3
1
1
2
1
2
0CH7106F621
10uF/16V
0CH7107F661
100uF/10V
0CH7226F651
22uF/16V
0CH7227F661
220uF/6.3V
0CH7476F661
47uF/10V
_
+
Regulator
Schottky Diode
Diode
Transistor
Tantalum Capacitor
