MODEL: FPD1510 DATE: 2001. 7. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C817 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C818 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C819 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C820 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C821 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C822 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C823 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C824 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C825 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C826 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C827 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C828 0CZZTAT002B SVP SANYO 10V 47UF M REEL OS-CON
C829 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C830 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C831 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C832 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C833 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C834 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C835 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C836 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C840 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C841 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C842 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C845 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SMD
C846 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
C847 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P)
D502 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 30V
D503 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 30V
D701 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D702 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D703 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D704 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D707 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D708 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D709 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D710 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D711 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D712 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D713 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D714 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D730 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D731 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D732 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D734 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D735 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D736 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D737 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D738 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D739 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D740 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
D741 0DS226009AA KDS226 TP KEC SOT-23 80V 300MA
ZD701 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 200MW
ZD702 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 200MW
ZD703 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 200MW
ZD704 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 200MW
ZD705 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 200MW
ZD806 0DR190309AA MBRS190T3 TP MOTOROLA 403A-03
MODEL: FPD1510 DATE: 2001. 7. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
U201 0IPRPGN002A GM5010 GENESIS 208P,PQFP TRAY
U501 0IZZTSZ134A 42PIN SDIP BK OPT MICOM ASSY
U502 0ICS240813B CAT24WC08J-TE13 8P,SOIC R/TP 8K
U503 0ISS524202A S524C20D21-SCT0 8SOP-225 R/TP EE
U710 0ITI741400T SN74AC14DR 14,SOP R/TP HEX INVER
U801 0ISG497351A L4973D5.1 SO20 TP 3.5A S/DOWN S/
U802 0TF632509AA FDC6325L TP FAIRCHILD 8V 2.4A SM
U803 0IPMGFA003B RC1117S-2.5 FAIRCHILD SOT-223 R/
U811 0IPMGSJ001A EZ1086CM-3.3 SEMTECH TO-263 R/TP
U820 0IRH033200A BA033FP-E2 MOLD-3 TP REGULATOR
U821 0IRH033200A BA033FP-E2 MOLD-3 TP REGULATOR
L201 6210TCE001P HB-1S2012-121JT CERATECH 2012MM
L202 6210TCE001P HB-1S2012-121JT CERATECH 2012MM
L203 6210TCE001P HB-1S2012-121JT CERATECH 2012MM
L204 6210TCE001P HB-1S2012-121JT CERATECH 2012MM
L205 6210TCE0011 V/C CERATEC R/TP HB-1H2012-221JT
L206 6210TCE0011 V/C CERATEC R/TP HB-1H2012-221JT
L701 6210TCT002B ACB2012M-300-T TDK , CHIP BEAD,L
L702 6210TCT002B ACB2012M-300-T TDK , CHIP BEAD,L
L703 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/T
L704 6210TCE001C HB-1T3216-500JT CERATEC 3216MM C
L705 6210TCE001C HB-1T3216-500JT CERATEC 3216MM C
L707 6210TCE001C HB-1T3216-500JT CERATEC 3216MM C
L708 6210TCE001C HB-1T3216-500JT CERATEC 3216MM C
L710 6210TCE001D HB-1M2012-601JT CERATEC 2012MM R
L720 6210TCE001P HB-1S2012-121JT CERATECH 2012MM
L801 6140TBZ007A DR10*7(K-30) 100UH 0.4MM 34.5T S
L802 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/T
L803 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/T
L804 6210TCE001C HB-1T3216-500JT CERATEC 3216MM C
L805 6210TCE001C HB-1T3216-500JT CERATEC 3216MM C
L810 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/T
L811 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/T
Q501 0IKE704200J KIA7042AF SOT-89 TP 4.2V VOLTAGE
Q701 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 GEN
Q702 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 GEN
R130 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R201 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R202 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R218 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R219 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R220 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R221 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R222 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R223 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R224 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R225 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R227 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R229 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R231 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R233 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R234 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
- 22 -
DIODEs
ICs
COILs & COREs
TRANSISTOR
RESISTORs
