MODEL: FPD1510 DATE: 2001. 7. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R235 0RH2201D622 2.2K 1/10W P-TYPE TAPPING
R236 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R239 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R241 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R243 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R245 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R247 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R249 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R251 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R253 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R255 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R257 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R259 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R260 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R261 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R262 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R263 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R264 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R265 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R266 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R267 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R501 0RJ1004D677 1000000 OHM 1/10 W 5% 1608 R/TP
R502 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R508 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R509 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R511 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R512 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R513 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R516 0RH2200D622 220 1/10W 5 D.R/TP
R518 0RH2200D622 220 1/10W 5 D.R/TP
R522 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R523 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R524 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R525 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R526 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R527 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R528 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R529 0RJ7502D677 75K OHM 1/10 W 5% 1608 R/TP
R531 0RJ3302D677 33K OHM 1/10 W 5% 1608 R/TP
R532 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R533 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R534 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R535 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R536 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R537 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R538 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R539 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R540 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R542 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R543 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R544 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R545 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R548 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R549 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R550 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R551 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R560 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R580 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R701 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R703 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R704 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R705 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
MODEL: FPD1510 DATE: 2001. 7. 10.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R706 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R707 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R708 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R709 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R710 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R713 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R714 0RJ1801D677 1.8K OHM 1/10 W 5% 1608 R/TP
R715 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R716 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R717 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R718 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R719 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R720 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R721 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R722 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R723 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R724 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R725 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R729 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R730 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R731 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R801 0RJ3602D677 36K OHM 1/10 W 5% 1608 R/TP
R802 0RJ3602D677 36K OHM 1/10 W 5% 1608 R/TP
R803 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R804 0RJ9101D677 9.1K OHM 1/10 W 5% 1608 R/TP
R805 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R806 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R809 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R810 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R820 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R821 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R822 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R823 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R824 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R825 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R826 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R827 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R828 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R829 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
J801 6612TAH003A DJ-023 KSD R/ANGLE LB563B
X201 6202TST001E SX-1 SUNNY CHIP 24MHZ 30PPM 20PF
X501 6202TST001E SX-1 SUNNY CHIP 24MHZ 30PPM 20PF
C1 0CN1040K949 0.1M 50V Z F TA52
C2 0CN1040K949 0.1M 50V Z F TA52
C3 0CN1040K949 0.1M 50V Z F TA52
R1 0RD4701Q609 4.70K 1/4W(3 5% TA52
R2 0RD4701Q609 4.70K 1/4W(3 5% TA52
R3 0RD8200Q609 820 1/4W(3 5% TA52
R4 0RD8200Q609 820 1/4W(3 5% TA52
R5 0RD1501Q609 1.50K 1/4W(3 5% TA52
R6 0RD1501Q609 1.50K 1/4W(3 5% TA52
R7 0RD2201Q609 2.20K 1/4W(3 5% TA52
SW1 140-058D SKHV10911A LGEC NON 12 20 HORIZE
SW2 140-058D SKHV10911A LGEC NON 12 20 HORIZE
SW3 140-058D SKHV10911A LGEC NON 12 20 HORIZE
SW4 140-058D SKHV10911A LGEC NON 12 20 HORIZE
- 23 -
OTHERs
CONTROL BOARD
