Gateway FPD1520 Service Manual

- 24 -
EXPLODED VIEW PARTS LIST(HYUNDAI Hydis Module)
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
A
Part No.
3091TKL036A
6304FHD001C
3809TKL017C
3043TKK078D
6633TZA003K
or 6633TZA009A
6871TST245C
4951TKS079C
4951TKK085A
6871TPT223A
6871TMT287B
6631T11012U
4951TKK084B
332-105F
332-068T
6866TD9001Q
or 6866TD9001L
3313TL5039B
Description
CABINET ASSEMBLY, LG56AM G/WAY >PC+ABS< 12446B, ANALOG VER.
LCD, HT15X13-200(A) HYUNDAI 15.0 INCH XGA(1024 X 768) TFT COLOR LVDS
BACK COVER ASSEMBLY, LG56BP/BQ . POWER BUILT IN("B"-CORE)
TILT SWIVEL ASSEMBLY, "LG56AM >PC+ABS< 12446B,VESA PLATE PAINTING"
INVERTER ASSEMBLY, SAMSUNG LG1509-1 4 LAMP,LG56AM
INVERTER ASSEMBLY, LG-PHILIPS NMC 1509-02 4 LAMP, LG56AM
PWB(PCB) ASSEMBLY, SUB, LG56BP/BQ CONTROL TOTAL G/WAY
METAL ASSEMBLY, FRAME MAIN,LG56BQ(ADAPTER)
METAL ASSEMBLY, SHIELD POWER PCB
PWB(PCB) ASSEMBLY,POWER LG56BP/Q POWER TOTAL G/WAY CL-32
PWB(PCB) ASSEMBLY,MAIN, LG56BQ XAGC G/WAY CL-32 TOTAL
CONNECTOR ASSEMBLY, 20P H-H 100MM UL20276 LG56BQ
METAL ASSEMBLY, REAR LG56BQ
SCREW, PVS+4*10(MSWR/FZMW)
SCREW, PPB+3*10 (MSWR/FZMW1)
CABLE,D-SUB, UL 2990-9C(7.5) DT 1870MM COOL GRAY 3C CG992E DM
CABLE,D-SUB, UL 2990-9C(7.5) DT 1870MM COOL GRAY 3C LB680A DM
MAIN TOTAL ASSEMBLY, LG56BQ G/WAY CL-32
