Gateway FPD1520 Service Manual

MODEL: FPD1520(LG Philips Module) DATE: 2002. 01. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
BD901 0DD260000BE D2SB60 SHINDENKEN
D901 0DD400709CB UF4007 TP G.I DO204AL 100
D903 0DRGS00281A MBRF10H100CT GENERAL SEMIC
D904 0DR400409AB UF4004 TP G.I DO204AL 400V
D906 0DR206000AA MBRF2060CT BK G.I ITO220 6
D908 0DZ620009AG P6KE200 TP G.I D015 5W 200
IC901 0IPMGPF004A TOP246F POWER INTEGRATION
IC904 0ISS431000A KA431AZ (LM431AZ)
R901 0RD6803A609 680K OHM 1/2 W (7.0) 5% TA
R902 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R903 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R904 0RD4704Q609 4.7M OHM 1/4 W (3.4) 5% TA
R905 0RD4704Q609 4.7M OHM 1/4 W (3.4) 5% TA
R906 0RX4702J609 47K OHM 1 W 5% TA52
R907 0RD0471Q609 4.70 1/4W(3 5% TA52
R908 0RD0681Q609 6.8 OHM 1/4 W (3.4) 5% TA5
R909 0RD1001Q609 1K 1/4W(3 5% TA52
R913 0RN1302F409 13K 1/6W 1% TA52
R917 0RD1201Q609 1.20K 1/4W(3 5% TA52
R918 0RD1000Q609 100 1/4W(3 5% TA52
R920 0RN1302F409 13K 1/6W 1% TA52
R921 0RN2701F409 2.70K 1/6W 1% TA52
R923 0RD1202Q609 12K 1/4W(3 5% TA52
T901 6170TMZ133A EER3016 1200 UH V-10PIN LG
TH901 6322A00002B SCK-102L THINKING 10OHM 20
F901 0FZZTTH001E TIME LAG HBC 2153.15MXE(LE
LF901 6200TZZ001B “- 0 BK L/FILTER, 9MH,LG56B”
P901 6620TKB002C “BCP031S-A,BAE EUN AC UNIVE”
P902 6631T20008R 5P H-B 80MM UL1061 AWG 26
PC901 0ILI817000E LTV-817M B 4P BK PHOTO COU
C1 0CN1040K949 0.1M 50V Z F TA52
C2 0CN1040K949 0.1M 50V Z F TA52
C3 0CN1040K949 0.1M 50V Z F TA52
ZD1 0DZ560009CE MTZJ5.6B TP ROHM-K DO34 5
ZD2 0DZ560009CE MTZJ5.6B TP ROHM-K DO34 5
LED1 0DL305029BA LTL-305DJ-0C2 TP LITEON GR
R1 0RD4701Q509 4.7K OHM 1/4 W (3.4) 2% TA
R2 0RD4701Q509 4.7K OHM 1/4 W (3.4) 2% TA
R3 0RD1501Q509 1.5K OHM 1/4 W (3.4) 2% TA
R4 0RD1501Q509 1.5K OHM 1/4 W (3.4) 2% TA
R5 0RD3301Q509 3.3K OHM 1/4 W (3.4) 2% TA
R6 0RD3301Q509 3.3K OHM 1/4 W (3.4) 2% TA
R7 0RD9101Q609 9.10K 1/4W(3 5% TA52
SW1 140-058D SKHV10911A LGEC NON 12 20
SW2 140-058D SKHV10911A LGEC NON 12 20
SW3 140-058D SKHV10911A LGEC NON 12 20
SW4 140-058D SKHV10911A LGEC NON 12 20
SW5 140-058D SKHV10911A LGEC NON 12 20
SW6 140-058D SKHV10911A LGEC NON 12 20
SW7 140-058E SKHV10910B LGEC NON 12V 20
- 27 -
CONTROL BOARD
