Gateway FPD1520 Service Manual

- 28 -
MODEL: FPD1520(Hydis Module) DATE: 2002. 01. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C201 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C202 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C203 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C204 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C205 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C206 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C207 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C208 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C209 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C210 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C211 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C212 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C214 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C215 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C220 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C223 0CC150CK41A 15PF 1608 50V 5% R/TP NP0
C224 0CC150CK41A 15PF 1608 50V 5% R/TP NP0
C225 0CC100CK41A 10PF 1608 50V 5% R/TP NP0
C226 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C230 0CC150CK41A 15PF 1608 50V 5% R/TP NP0
C232 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C235 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C236 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C254 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C255 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C256 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C257 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C258 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C259 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C261 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C262 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C269 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C270 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C271 0CK103CK51A 0.01UF 1608 50V 10% R/TP B
C401 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C402 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C403 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C404 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C405 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C501 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C502 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C503 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C504 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C505 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C506 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C507 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C508 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C509 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C512 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C513 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C514 0CH8106F611 10UF 16V M 85STD(CYL) R/TP
C515 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
MODEL: FPD1520(Hydis Module) DATE: 2002. 01. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C516 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C706 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C712 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C713 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C715 0CH8106J611 10UF 35V M 85STD(CYL) R/TP
C716 0CE107CH610 100UF SHL,SD 25V 20% BULK
C717 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C731 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C801 0CC102CK41A 1000PF 1608 50V 5% R/TP NP
C802 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C813 0CC102CK41A 1000PF 1608 50V 5% R/TP NP
C814 0CC102CK41A 1000PF 1608 50V 5% R/TP NP
C815 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C816 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C817 0CE107CF610 100UF SHL,SD 16V 20% BULK
C818 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C819 0CC102CK41A 1000PF 1608 50V 5% R/TP NP
C820 0CE107CF610 100UF SHL,SD 16V 20% BULK
C821 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C822 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C823 0CC102CK41A 1000PF 1608 50V 5% R/TP NP
C824 0CH8107F611 100UF 16V M 85STD(CYL) R/T
C825 0CE107CF610 100UF SHL,SD 16V 20% BULK
C826 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C827 0CC102CK41A 1000PF 1608 50V 5% R/TP NP
C828 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
C829 0CC102CK41A 1000PF 1608 50V 5% R/TP NP
C830 0CH8107F611 100UF 16V M 85STD(CYL) R/T
C831 0CH8107F611 100UF 16V M 85STD(CYL) R/T
C832 0CH8107F611 100UF 16V M 85STD(CYL) R/T
C833 0CE107CF610 100UF SHL,SD 16V 20% BULK
C835 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7
D701 0DS226009AA KDS226 TP KEC SOT-23 80V
D702 0DS226009AA KDS226 TP KEC SOT-23 80V
D703 0DS226009AA KDS226 TP KEC SOT-23 80V
D704 0DS226009AA KDS226 TP KEC SOT-23 80V
D705 0DS226009AA KDS226 TP KEC SOT-23 80V
D706 0DS226009AA KDS226 TP KEC SOT-23 80V
ZD501 0DZ910009FE UDZS 9.1B TP ROHM - - 9.1V
ZD701 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD32
ZD702 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD32
U201 0IPRPGA002A GMZAN2-160P GENESIS MICROC
U4 0IZZTSZ168B MYSON 42PIN BK OTP LG56BQ
U401 0ITH638300B THC63LVDM83R THINE 56P,TSS
U502 0ICS240813B CAT24WC08J-TE13 8P,SOIC R/
U701 0IMO741420B MC74HCT14ADR2 14P,SOIC TP
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
DIODEs
ICs
