Gateway FPD1520 Service Manual

MODEL: FPD1520(Hydis Module) DATE: 2002. 01. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
U802 0IRH033200A BA033FP-E2 MOLD-3 TP REGUL
U803 0ISS780500H KA78M05-R 3P,D-PAK TP 5V 0
U805 0IRH033000A BA033SFP P/MOLD-5 TP REGUL
U806 0IPMGON007A NCP1117ST25T3 ON SEMI SOT2
L201 6210TCE001P HB-1S2012-121JT CERATECH 2
L202 6210TCE001P HB-1S2012-121JT CERATECH 2
L203 6210TCE001P HB-1S2012-121JT CERATECH 2
L204 6210TCE001P HB-1S2012-121JT CERATECH 2
L701 6210TCE001S HU-1M2012-121 CERATECH 201
L702 6210TCE001P HB-1S2012-121JT CERATECH 2
L703 6210TCE001P HB-1S2012-121JT CERATECH 2
L704 6210TCE001P HB-1S2012-121JT CERATECH 2
L705 6210TCE001P HB-1S2012-121JT CERATECH 2
L706 6210TCE001P HB-1S2012-121JT CERATECH 2
L707 6210TCE001P HB-1S2012-121JT CERATECH 2
L708 6210TCE001S HU-1M2012-121 CERATECH 201
L710 6210TCE001G HH-1M3216-501 CERATEC 3216
L803 6210TCE001G HH-1M3216-501 CERATEC 3216
L804 6210TCE001G HH-1M3216-501 CERATEC 3216
L805 6210TCE001G HH-1M3216-501 CERATEC 3216
Q501 0IKE704200J KIA7042AF SOT-89 TP 4.2V V
Q502 0TR390409AE FAIRCHILD KST3904(LGEMTF)
Q505 0TR162309CA KSC1623 TP SAMSUNG SOT23
Q506 0TR162309CA KSC1623 TP SAMSUNG SOT23
Q701 0TR390409AE FAIRCHILD KST3904(LGEMTF)
R201 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R202 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R203 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R204 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R205 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R206 0RJ2701D677 2.7K OHM 1/10 W 5% 1608 R/
R207 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R208 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R209 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R210 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R401 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/T
R403 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R404 0RJ5601D477 5.6K OHM 1/10 W 1% 1608 R/
R501 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R502 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R503 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R504 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R505 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/T
R506 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R507 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/T
R508 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/T
R509 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R510 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R511 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R512 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R513 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/
R515 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
MODEL: FPD1520(Hydis Module) DATE: 2002. 01. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R516 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R517 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R518 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R519 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R520 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R521 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R522 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/T
R523 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R524 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R525 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R526 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R527 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R528 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R529 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R530 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R531 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R532 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/
R533 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/T
R534 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/T
R535 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/
R536 0RJ1004D677 1000000 OHM 1/10 W 5% 1608
R537 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R538 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/T
R539 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/T
R541 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R551 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R561 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R701 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R702 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R703 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R704 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R705 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/T
R706 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R707 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R708 0RJ2000D677 200 OHM 1/10 W 5% 1608 R/T
R709 0RJ2000D677 200 OHM 1/10 W 5% 1608 R/T
R711 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R712 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R713 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R714 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/T
R715 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R716 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R717 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R719 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/T
R721 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R733 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/
R734 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/
R805 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/T
R807 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/
RA501 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/T
RA502 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/T
X201 6202TST001A SX-1 SUNNY ,SMS, 14.31818M
X501 6202TST003D HC-49/SM5H KONY CHIP 12 MH
C901 0CBZTBU002D 0.33UF D 275V K M/PP NI FM
C902 0CKZTBU003D SC SAMWHA 250V 1000PF M BU
C903 0CKZTBU003D SC SAMWHA 250V 1000PF M BU
- 29 -
TRANSISTOR
RESISTORs
COILs & COREs
OTHERs
POWER BOARD
