- 8 -
WIRING DIAGRAM (HYUNDAI Hydis Module)
CN5
CN2
CN3
CN1
CN4
J1
J11
J705
J707
J706
J702
CONNECTOR ASS’Y
P/N: 6631T11012U
CONNECTOR ASS’Y
P/N: 6631T20015K
CONNECTOR ASS’Y
P/N: 6631T20008R
CONNECTOR ASS’Y
P/N: 6631T20010T
