Gateway FPD1520 Service Manual

- 9 -
DISASSEMBLY
1) Remove two screws (a) from Back cover.
Bottom
Top
BACK COVER REMOVAL
2) Set the Monitor as picture.
3) Release the bottom & side latch.
4) Set the Monitor face downward.
5) Remove the Back cover.
12V
(a)
(a)
(b)
(b)
(b)
(b)
(b)
(b)
(b)
(b)
(b)
(b)
(b)
(b)
(b) Latch Point
