Setting up the optional speaker bar
www.gateway.com
11
Setting up the optional speaker bar
Installing the speaker bar
To install the speaker bar:
Tips & Tricks
When using the speaker bar, we
recommend that you use the right-angle
video cable so the speaker bar does not
obstruct the cable.
1 Tilt the screen back, then center the speaker bar below the screen. Make
sure that the speakers face forward.
2 Tighten the two thumbscrews on the back of the speaker bar.
3 Connect the speaker bar’s USB power cord to any available USB port on
your computer or on the USB stand.
4 Connect the speaker bar’s headphone (green) and microphone (pink)
cables to your computer’s headphone and microphone jacks.
5 If it is not already on, turn on your computer.
Power/Volume control
Power indicator
Kensington lock slot
Headphone jack
Bass port Bass port
Microphone jack Headphone jack
8511808.book Page 11 Friday, November 17, 2006 9:56 AM
