REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
VX900T
SECTION 7
ELECTRICAL PARTS LIST
RESISTORS
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF = µF
INDUCTORS
• UH = µH, MMH = mH
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
Note:
Les composants identifies per un trame
et une marque
¡¡
¡¡
¡ sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by [ in this manual
have been carefully factory-selected for each
set in order to satisfy regulations regarding X-
ray radiation. Should replacement be required,
replace only with the value originally used.
• Items marked " * " are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
REF.NO. PART NO. DESCRIPTION REMARK
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
A
*A-1298-800-A A BOARD, COMPLETE
3-899-248-11 SCREW (M3X8)
4-382-854-01 SCREW (M3X8), P, SW (+)
CAPACITOR
C001 1-162-318-11 CERAMIC 0.001MF 10% 500V
C004 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C007 1-107-906-11 ELECT 10MF 20% 50V
C009 1-126-942-61 ELECT 1000MF 20% 25V
C010 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C011 1-106-220-00 MYLAR 0.1MF 10% 100V
C012 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C013 1-107-888-11 ELECT 47MF 20% 25V
C014 1-107-932-11 ELECT 47MF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C016 1-128-528-11 ELECT 470MF 20% 16V
C018 1-107-746-11 ELECT 10MF 20% 200V
C019 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C020 1-126-935-11 ELECT 470MF 20% 16V
C022 1-104-664-11 ELECT 47MF 20% 25V
C027 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C028 1-104-664-11 ELECT 47MF 20% 25V
C029 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C031 1-162-318-11 CERAMIC 0.001MF 10% 500V
C033 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C035 1-162-134-11 CERAMIC 470PF 10% 2KV
C037 1-101-006-00 CERAMIC 0.047MF 50V
C038 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C039 1-104-503-12 CERAMIC CHIP 0.1MF 10% 100V
C040 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C041 1-162-318-11 CERAMIC 0.001MF 10% 500V
C042 1-104-503-12 CERAMIC CHIP 0.1MF 10% 100V
C043 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C044 1-162-318-11 CERAMIC 0.001MF 10% 500V
C045 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C046 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C049 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C054 1-137-528-11 FILM 0.1MF 10% 250V
C055 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C057 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C058 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C059 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C060 1-126-963-11 ELECT 4.7MF 20% 50V
C061 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C062 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C090 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C092 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C104 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C106 1-117-450-11 FILM 0.47MF 10% 250V
C108 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C109 1-104-664-11 ELECT 47MF 20% 25V
C111 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C119 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C121 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C122 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C130 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C152 1-126-933-11 ELECT 100MF 20% 16V
C204 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C206 1-117-450-11 FILM 0.47MF 10% 250V
C208 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C211 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C221 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C222 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C230 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
