Gateway VX900T User Manual

— 42 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
VX900T
A
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
C252 1-126-933-11 ELECT 100MF 20% 16V
C304 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C306 1-117-450-11 FILM 0.47MF 10% 250V
C308 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C311 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C319 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C321 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C322 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C330 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C352 1-126-933-11 ELECT 100MF 20% 16V
CONNECTOR
CN301 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN302 1-695-915-11 TAB (CONTACT)
CN303 1-695-915-11 TAB (CONTACT)
CN305 * 1-564-512-11 PLUG, CONNECTOR 9P
CN306 * 1-564-511-11 PLUG, CONNECTOR 8P
CN308 1-695-915-11 TAB (CONTACT)
CN309 * 1-564-510-11 PLUG, CONNECTOR 7P
CN310 * 1-779-944-21 PIN, CONNECTOR (PC BOARD) 4P
CN311 * 1-564-508-11 PLUG, CONNECTOR 5P
DIODE
D002 8-719-911-19 DIODE 1SS119-25
D003 8-719-911-19 DIODE 1SS119-25
D004 8-719-911-19 DIODE 1SS119-25
D005 8-719-911-19 DIODE 1SS119-25
D007 8-719-109-89 DIODE RD5.6ESB2
D008 8-719-109-89 DIODE RD5.6ESB2
D014 8-719-911-19 DIODE 1SS119-25
D015 8-719-911-19 DIODE 1SS119-25
D022 8-719-911-19 DIODE 1SS119-25
D023 8-719-921-54 DIODE MTZJ-6.2B
D024 8-719-109-69 DIODE RD3.6ESB2
D025 8-719-921-54 DIODE MTZJ-6.2B
D104 8-719-970-83 DIODE HSS82
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D108 8-719-911-19 DIODE 1SS119-25
D109 8-719-901-83 DIODE 1SS83
D111 8-719-062-51 DIODE 1PS226-115
D120 8-719-911-19 DIODE 1SS119-25
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D208 8-719-911-19 DIODE 1SS119-25
D209 8-719-901-83 DIODE 1SS83
D211 8-719-062-51 DIODE 1PS226-115
D220 8-719-911-19 DIODE 1SS119-25
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
D308 8-719-911-19 DIODE 1SS119-25
D309 8-719-901-83 DIODE 1SS83
D311 8-719-062-51 DIODE 1PS226-115
D320 8-719-911-19 DIODE 1SS119-25
FERRITE BEAD
FB001 1-412-911-31 FERRITE
FB002 1-412-911-31 FERRITE
FB004 1-412-911-31 FERRITE
FB005 1-412-911-31 FERRITE
FB006 1-412-911-31 FERRITE
FB009 1-412-911-31 FERRITE
FB010 1-412-911-31 FERRITE
FB011 1-412-911-31 FERRITE
FB012 1-412-911-31 FERRITE
FB015 1-412-911-31 FERRITE
FB016 1-412-911-31 FERRITE
FB017 1-412-911-31 FERRITE
FB018 1-412-911-31 FERRITE
FB019 1-412-911-31 FERRITE
FB020 1-412-911-31 FERRITE
FB101¡ 1-500-419-21 FERRITE
FB102¡ 1-216-295-91 SHORT
FB104 1-412-911-31 FERRITE
FB110 1-412-911-31 FERRITE
FB111 1-412-911-31 FERRITE
FB201¡ 1-500-419-21 FERRITE
FB202¡ 1-216-295-91 SHORT
FB210 1-412-911-31 FERRITE
FB211 1-412-911-31 FERRITE
FB301¡ 1-500-419-21 FERRITE
FB302¡ 1-216-295-91 SHORT
FB310 1-412-911-31 FERRITE
FB311 1-412-911-31 FERRITE
IC
IC001 8-752-085-07 IC CXA2066S
IC002 8-759-530-91 IC LM2403
IC003 8-759-532-60 IC SNY432
IC004 8-759-532-61 IC STV5109
IC005 8-759-100-96 IC UPC4558G2
