Gateway VX900T User Manual

— 43 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
VX900T
Les composants identifies per un trame
et une marque
¡¡
¡¡
¡ sont critiques pour la
securite. Ne les remplacer que par une
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
A
IC006 8-759-269-07 IC SN74HCT02ANS-E20
IC009 8-759-701-56 IC NJM78M05FA
JACK
J001¡ 1-251-598-11 SOCKET, CRT
CHIP CONDUCTOR
JR001 1-216-296-91 SHORT
JR002 1-216-296-91 SHORT
JR003 1-216-296-91 SHORT
JR004 1-216-296-91 SHORT
JR005 1-216-296-91 SHORT
JR006 1-216-296-91 SHORT
COIL
L003 1-412-911-31 FERRITE
L004 1-412-529-11 INDUCTOR 22UH
L101 1-249-398-11 CARBON 27 5% 1/4W
L201 1-414-137-31 INDUCTOR 22UH
L301 1-249-398-11 CARBON 27 5% 1/4W
TRANSISTOR
Q001 8-729-032-61 TRANSISTOR 2SC5022-02
Q002 8-729-216-22 TRANSISTOR 2SA1162-G
Q004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R001 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R004 1-217-671-11 RES, CHIP 1 5% 1/10W
R006 1-216-025-91 RES, CHIP 100 5% 1/10W
R007 1-216-025-91 RES, CHIP 100 5% 1/10W
R009 1-216-073-00 RES, CHIP 10K 5% 1/10W
R011 1-216-073-00 RES, CHIP 10K 5% 1/10W
R012 1-216-073-00 RES, CHIP 10K 5% 1/10W
R013 1-216-025-91 RES, CHIP 100 5% 1/10W
R014 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R017 1-216-025-91 RES, CHIP 100 5% 1/10W
R018 1-216-025-91 RES, CHIP 100 5% 1/10W
R019 1-216-059-00 RES, CHIP 2.7K 5% 1/10W
R020 1-216-025-91 RES, CHIP 100 5% 1/10W
R021 1-216-025-91 RES, CHIP 100 5% 1/10W
R022 1-216-025-91 RES, CHIP 100 5% 1/10W
R023 1-216-049-91 RES, CHIP 1K 5% 1/10W
R024 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R025 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R029 1-216-099-00 RES, CHIP 120K 5% 1/10W
R030 1-216-025-91 RES, CHIP 100 5% 1/10W
R031 1-216-049-91 RES, CHIP 1K 5% 1/10W
R032 1-216-025-91 RES, CHIP 100 5% 1/10W
R033 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R034 1-216-081-00 RES, CHIP 22K 5% 1/10W
R045 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R046 1-216-097-91 RES, CHIP 100K 5% 1/10W
R047 1-216-073-00 RES, CHIP 10K 5% 1/10W
R048 1-211-885-21 METAL 2.2M 5% 1W
R049 1-216-093-91 RES, CHIP 68K 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R054 1-216-049-91 RES, CHIP 1K 5% 1/10W
R056 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R058 1-216-041-00 RES, CHIP 470 5% 1/10W
R060 1-249-408-11 CARBON 180 5% 1/4W
R064 1-202-830-00 SOLID 10K 20% 1/2W
R104 1-216-021-00 RES, CHIP 68 5% 1/10W
R105 1-215-477-00 METAL 220K 1% 1/4W
R106 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R107 1-216-049-91 RES, CHIP 1K 5% 1/10W
R108 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R109 1-216-121-91 RES, CHIP 1M 5% 1/10W
R110 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R111 1-249-404-00 CARBON 82 5% 1/4W F
R112 1-215-461-00 METAL 47K 1% 1/4W
R115 1-216-107-00 RES, CHIP 270K 5% 1/10W
R116 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R117 1-216-001-00 RES, CHIP 10 5% 1/10W
R118 1-216-017-91 RES, CHIP 47 5% 1/10W
R119 1-249-437-11 CARBON 47K 5% 1/4W
R120 1-249-437-11 CARBON 47K 5% 1/4W
R122 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R130 1-216-019-00 RES, CHIP 56 5% 1/10W
R151 1-202-549-00 SOLID 100 20% 1/2W
R161 1-215-394-00 METAL 75 1% 1/4W
R204 1-216-021-00 RES, CHIP 68 5% 1/10W
R205 1-215-477-00 METAL 220K 1% 1/4W
R206 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R207 1-216-049-91 RES, CHIP 1K 5% 1/10W
R208 1-216-653-11 METAL CHIP 1.2K 0.50% 1/10W
R209 1-216-121-91 RES, CHIP 1M 5% 1/10W
R210 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R211 1-249-405-11 CARBON 100 5% 1/4W F
R212 1-215-461-00 METAL 47K 1% 1/4W
R215 1-216-107-00 RES, CHIP 270K 5% 1/10W
