REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
VX900T
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
R216 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R217 1-216-017-91 RES, CHIP 47 5% 1/10W
R218 1-216-017-91 RES, CHIP 47 5% 1/10W
R219 1-249-437-11 CARBON 47K 5% 1/4W
R220 1-249-437-11 CARBON 47K 5% 1/4W
R222 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R230 1-216-019-00 RES, CHIP 56 5% 1/10W
R233 1-216-013-00 RES, CHIP 33 5% 1/10W
R251 1-202-549-00 SOLID 100 20% 1/2W
R261 1-215-394-00 METAL 75 1% 1/4W
R304 1-216-021-00 RES, CHIP 68 5% 1/10W
R305 1-215-477-00 METAL 220K 1% 1/4W
R306 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R307 1-216-049-91 RES, CHIP 1K 5% 1/10W
R308 1-216-653-11 METAL CHIP 1.2K 0.50% 1/10W
R309 1-216-121-91 RES, CHIP 1M 5% 1/10W
R310 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R311 1-249-405-11 CARBON 100 5% 1/4W F
R312 1-215-461-00 METAL 47K 1% 1/4W
R315 1-216-107-00 RES, CHIP 270K 5% 1/10W
R316 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R317 1-216-017-91 RES, CHIP 47 5% 1/10W
R318 1-216-017-91 RES, CHIP 47 5% 1/10W
R319 1-249-437-11 CARBON 47K 5% 1/4W
R320 1-249-437-11 CARBON 47K 5% 1/4W
R322 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R330 1-216-019-00 RES, CHIP 56 5% 1/10W
R351 1-202-549-00 SOLID 100 20% 1/2W
R361 1-215-394-00 METAL 75 1% 1/4W
SPARK GAP
SG001¡ 1-519-422-11 GAP, SPARK
SG002¡ 1-517-499-21 GAP, SPARK
SG101¡ 1-517-499-21 GAP, SPARK
SG201¡ 1-517-499-21 GAP, SPARK
SG301¡ 1-517-499-21 GAP, SPARK
CRYSTAL
X001 1-567-890-11 VIBRATOR, CRYSTAL
* A-1346-800-B D BOARD, COMPLETE
* 1-533-725-11 HOLDER, FUSE
3-710-578-01 COVER, VOLUME, 6 MOLD
3-899-248-11 SCREW (M3X8)
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-11 SCREW (M3X10), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
CAPACITOR
C401 1-126-941-11 ELECT 470MF 20% 25V
C402 1-137-426-11 FILM 0.47MF 10% 100V
C403 1-126-969-11 ELECT 220MF 20% 50V
C404 1-126-941-11 ELECT 470MF 20% 25V
C406 1-137-366-11 FILM 0.0022MF 5% 50V
C407 1-137-367-11 FILM 0.0033MF 5% 50V
C409 1-126-968-11 ELECT 100MF 20% 50V
C501 1-137-370-11 FILM 0.01MF 5% 50V
C502 1-102-228-00 CERAMIC 470PF 10% 500V
C503 1-104-664-11 ELECT 47MF 20% 25V
C504 1-107-648-91 ELECT 100MF 20% 200V
C505 1-117-879-91 CAPACITOR 0.01MF 10% 250V
C506 1-117-959-11 FILM 4700PF 3% 1.8KV
C507 1-107-444-11 CERAMIC 100PF 5% 2KV
C508 1-136-481-11 MYLAR 0.0022MF 10% 100V
C509 1-137-370-11 FILM 0.01MF 5% 50V
C510 1-102-973-00 CERAMIC 100PF 5% 50V
C511 1-136-169-00 FILM 0.22MF 5% 50V
C512 1-126-964-11 ELECT 10MF 20% 50V
C513 1-107-649-11 ELECT 2.2MF 20% 250V
C514 1-117-955-11 FILM 0.17MF 5% 400V
C515 1-115-524-11 FILM 1.5MF 5% 250V
C516 1-107-888-11 ELECT 47MF 20% 25V
C517 1-137-370-11 FILM 0.01MF 5% 50V
C518 1-115-520-11 FILM 0.68MF 5% 250V
C519 1-115-516-11 FILM 0.33MF 5% 250V
C520 1-115-512-11 FILM 0.15MF 5% 250V
C521 1-115-509-11 FILM 0.068MF 5% 250V
C522 1-117-953-11 FILM 0.033MF 5% 400V
C523 1-137-370-11 FILM 0.01MF 5% 50V
C524 1-137-370-11 FILM 0.01MF 5% 50V
C525 1-137-370-11 FILM 0.01MF 5% 50V
C526 1-137-370-11 FILM 0.01MF 5% 50V
C527 1-107-651-11 ELECT 4.7MF 20% 250V
C528 1-162-115-00 CERAMIC 330PF 10% 2KV
