REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
VX900T
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
C921 1-117-879-91 CAPACITOR 0.01MF 10% 250V
C922 1-117-626-11 FILM 2000PF 3% 1.2KV
C923 1-137-367-11 FILM 0.0033MF 5% 50V
C924 1-136-105-00 FILM 0.33MF 5% 200V
C925 1-136-165-00 FILM 0.1MF 5% 50V
C926 1-137-401-11 FILM 0.22MF 10% 100V
C927 1-106-220-00 MYLAR 0.1MF 10% 100V
C929 1-126-965-11 ELECT 22MF 20% 50V
C930 1-137-370-11 FILM 0.01MF 5% 50V
C931 1-115-349-51 CERAMIC 0.01MF 2KV
C933 1-115-349-51 CERAMIC 0.01MF 2KV
C934 1-126-964-11 ELECT 10MF 20% 50V
CONNECTOR
CN501 *1-580-798-11 CONNECTOR PIN (DY) 6P
CN600¡ *1-785-290-11 INLET, AC 3P(W0TH NOISE FILTER
CN601 *1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN603 *1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN605 *1-506-371-00 PIN, CONNECTOR 2P
CN606 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN607 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN608 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN609 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN610 1-695-915-11 TAB (CONTACT)
CN702 *1-779-944-21 PIN, CONNECTOR (PC BOARD) 4P
CN901 *1-508-879-11 BASE POST 4P
CN904 1-695-915-11 TAB (CONTACT)
CN999 1-695-915-11 TAB (CONTACT)
DIODE
D401 8-719-979-58 DIODE EGP10D
D405 8-719-911-19 DIODE 1SS119-25
D501 8-719-110-49 DIODE RD18ESB2
D502 8-719-975-77 DIODE SB340
D503 8-719-110-49 DIODE RD18ESB2
D504 8-719-061-21 DIODE FMQ-G5FMS
D505 8-719-052-86 DIODE D2L40-TA
D506 8-719-109-85 DIODE RD5.1ESB2
D508 8-719-911-19 DIODE 1SS119-25
D511 8-719-109-85 DIODE RD5.1ESB2
D601¡ 8-719-025-88 DIODE GBU4JL-6088
D603 8-719-110-49 DIODE RD18ESB2
D604¡ 8-719-050-84 DIODE RB441Q-40T-77
D605 8-719-979-58 DIODE EGP10D
D608 8-719-050-84 DIODE RB441Q-40T-77
D610¡ 8-719-979-84 DIODE EGP20DPKG23
D614¡ 8-719-110-08 DIODE RD8.2ESB2
D615 8-719-053-19 DIODE UF4007G23
D617 8-719-911-19 DIODE 1SS119-25
D618¡ 8-719-970-83 DIODE HSS82
D619¡ 8-719-050-84 DIODE RB441Q-40T-77
D631¡ 8-719-911-19 DIODE 1SS119-25
D632¡ 8-719-110-08 DIODE RD8.2ESB2
D633¡ 8-719-982-36 DIODE MTZJ-39B
D640¡ 8-719-911-19 DIODE 1SS119-25
D641¡ 8-719-109-63 DIODE RD3.0ESB2
D648 8-719-027-43 DIODE S2L20UF
D649 8-719-027-43 DIODE S2L20UF
D650 8-719-067-68 DIODE FMC-26UA
D651 8-719-031-78 DIODE S2L40F
D652 8-719-071-35 DIODE D4L20U
D653 8-719-071-35 DIODE D4L20U
D654 8-719-071-35 DIODE D4L20U
D655 8-719-071-35 DIODE D4L20U
D656 8-719-071-35 DIODE D4L20U
D660 8-719-109-89 DIODE RD5.6ESB2
D670 8-719-911-19 DIODE 1SS119-25
D802¡ 8-719-109-92 DIODE RD6.2ESB1
D803 8-719-911-19 DIODE 1SS119-25
D901 8-719-110-49 DIODE RD18ESB2
D902 8-719-052-86 DIODE D2L40-TA
D903 8-719-110-49 DIODE RD18ESB2
D904 8-719-970-83 DIODE HSS82
D905 8-719-028-72 DIODE RGP02-17EL-6433
D906 8-719-028-72 DIODE RGP02-17EL-6433
D908¡ 8-719-110-42 DIODE RD15ESB3
D909¡ 8-719-109-85 DIODE RD5.1ESB2
FUSE
F601¡ 1-576-231-11 FUSE (H.B.C.) 4A/250V
FERRITE BEAD
FB501 1-412-911-31 FERRITE
FB502 1-412-911-31 FERRITE
FB503 1-412-911-31 FERRITE
FB601 1-412-911-31 FERRITE
FB602 1-412-911-31 FERRITE
FB603 1-412-911-31 FERRITE
FB604 1-412-911-31 FERRITE
FB605 1-410-396-41 FERRITE 0.45UH
FB606 1-412-911-31 FERRITE
FB607¡ 1-410-396-41 FERRITE 0.45UH
