REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
VX900T
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
FB608 1-412-911-31 FERRITE
FB609 1-412-911-31 FERRITE
FB610 1-412-911-31 FERRITE
FB611 1-412-911-31 FERRITE
FB899 1-412-911-31 FERRITE
FB901 1-412-911-31 FERRITE
FB902 1-412-911-31 FERRITE
FB903 1-412-911-31 FERRITE
FB904 1-412-911-31 FERRITE
FB999 1-412-911-31 FERRITE
IC
IC401 8-759-339-59 IC TDA8177
IC502 8-759-803-42 IC LA6500-FA
IC601¡ 8-759-498-08 IC AN8037
IC603¡ 8-749-010-64 PHOTO COUPLER PC123F2
IC604 8-749-013-76 IC PQ6RD83B
IC605¡ 8-759-072-98 IC TDA8138A
IC606¡ 8-749-010-64 PHOTO COUPLER PC123F2
IC652¡ 8-759-540-60 IC TL431BCLPRA
IC701 8-749-015-00 IC STK391-110
IC702 8-759-803-42 IC LA6500-FA
IC703 8-749-015-00 IC STK391-110
IC704 8-759-822-38 IC LA6510
IC805¡ 8-759-478-76 IC UPC5021-109
COIL
L501 1-412-541-21 INDUCTOR 220UH
L502 1-416-747-11 COIL, HORIZONTAL LINEARITY
L503 1-416-367-11 COIL, HORIZONTAL CENTER
L504 1-406-677-11 INDUCTOR 10MMH
L505 1-406-673-21 INDUCTOR 2.2MMH
L506 1-412-521-31 INDUCTOR 4.7UH
L650 1-412-537-31 INDUCTOR 100UH
L651 1-412-537-31 INDUCTOR 100UH
L652 1-406-665-11 INDUCTOR 100UH
L653 1-406-665-11 INDUCTOR 100UH
L654 1-406-665-11 INDUCTOR 100UH
L655 1-406-665-11 INDUCTOR 100UH
L702 1-412-537-31 INDUCTOR 100UH
L703 1-412-537-31 INDUCTOR 100UH
L801 1-408-615-31 INDUCTOR 100UH
L901 1-412-537-31 INDUCTOR 100UH
L902 1-406-659-11 INDUCTOR 10UH
FILTER
LF602¡ 1-433-446-11 TRANSFORMER, LINE FILTER
TRANSISTOR
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q503 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q504¡ 8-729-042-34 TRANSISTOR IRFU110A
Q505 8-729-045-51 TRANSISTOR 2SC5530-01
Q506 8-729-043-63 TRANSISTOR IRFI9634G-LF35
Q507 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q508 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q509 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q510 8-729-043-72 TRANSISTOR IRLI530GSLF33
Q511 8-729-043-72 TRANSISTOR IRLI530GSLF33
Q512 8-729-043-72 TRANSISTOR IRLI530GSLF33
Q513 8-729-043-72 TRANSISTOR IRLI530GSLF33
Q514 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q515 8-729-140-50 TRANSISTOR 2SC3209LK
Q516 8-729-326-11 TRANSISTOR 2SC2611
Q517 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q518 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q601¡ 8-729-141-83 TRANSISTOR 2SB1094-LK
Q602¡ 8-729-046-72 TRANSISTOR IRFIBC44LCLF65
Q605¡ 8-729-029-86 TRANSISTOR DTC124ESA
Q606¡ 8-729-029-86 TRANSISTOR DTC124ESA
Q607¡ 8-729-029-86 TRANSISTOR DTC124ESA
Q640¡ 8-729-029-86 TRANSISTOR DTC124ESA
Q656¡ 8-729-029-86 TRANSISTOR DTC124ESA
Q657¡ 8-729-029-86 TRANSISTOR DTC124ESA
Q658¡ 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q670 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2
Q706 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q707 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q801 8-729-029-86 TRANSISTOR DTC124ESA
Q802 8-729-029-86 TRANSISTOR DTC124ESA
Q901 8-729-043-63 TRANSISTOR IRFI9634G-LF35
Q902 8-729-045-22 TRANSISTOR FS7KM-18A-AY
RESISTOR
R401 1-249-383-11 CARBON 1.5 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
R403 1-214-796-00 METAL 1.5 1% 1/2W
R404 1-215-449-00 METAL 15K 1% 1/4W
R405 1-214-796-00 METAL 1.5 1% 1/2W
