Gateway VX900T User Manual

— 48 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
VX900T
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
R406 1-215-433-00 METAL 3.3K 1% 1/4W
R407 1-249-397-11 CARBON 22 5% 1/4W F
R409 1-215-449-00 METAL 15K 1% 1/4W
R410 1-215-433-00 METAL 3.3K 1% 1/4W
R416 1-249-429-11 CARBON 10K 5% 1/4W
R417 1-247-895-91 CARBON 470K 5% 1/4W
R418 1-247-887-00 CARBON 220K 5% 1/4W
R501 1-249-421-11 CARBON 2.2K 5% 1/4W
R502 1-249-417-11 CARBON 1K 5% 1/4W
R504 1-247-807-31 CARBON 100 5% 1/4W
R505 1-247-863-91 CARBON 22K 5% 1/4W
R506 1-215-888-00 METAL OXIDE 220 5% 2W F
R507 1-249-381-11 CARBON 1 5% 1/4W F
R509 1-216-392-11 METAL OXIDE 1.8 5% 3W F
R510 1-216-392-11 METAL OXIDE 1.8 5% 3W F
R511 1-216-423-11 METAL OXIDE 27 5% 1W F
R512 1-249-397-11 CARBON 22 5% 1/4W F
R513 1-249-429-11 CARBON 10K 5% 1/4W
R514 1-249-425-11 CARBON 4.7K 5% 1/4W
R515 1-249-437-11 CARBON 47K 5% 1/4W
R516 1-214-838-00 METAL 82 1% 1/2W
R517 1-215-453-00 METAL 22K 1% 1/4W
R518 1-215-469-00 METAL 100K 1% 1/4W
R519 1-249-421-11 CARBON 2.2K 5% 1/4W
R520 1-215-886-11 METAL OXIDE 100 5% 2W F
R521 1-214-838-00 METAL 82 1% 1/2W
R522 1-260-312-11 CARBON 47 5% 1/2W
R523 1-260-312-11 CARBON 47 5% 1/2W
R525 1-249-437-11 CARBON 47K 5% 1/4W
R526 1-215-387-00 METAL 39 1% 1/4W
R527 1-249-437-11 CARBON 47K 5% 1/4W
R528 1-249-437-11 CARBON 47K 5% 1/4W
R529 1-249-437-11 CARBON 47K 5% 1/4W
R530 1-249-437-11 CARBON 47K 5% 1/4W
R536 1-247-903-00 CARBON 1M 5% 1/4W
R537 1-249-417-11 CARBON 1K 5% 1/4W
R538 1-249-417-11 CARBON 1K 5% 1/4W
R539 1-249-411-11 CARBON 330 5% 1/4W
R540 1-247-815-91 CARBON 220 5% 1/4W
R541 1-215-905-11 METAL OXIDE 10 5% 3W F
R542 1-215-449-00 METAL 15K 1% 1/4W
R543 1-249-437-11 CARBON 47K 5% 1/4W
R545 1-215-421-00 METAL 1K 1% 1/4W
R546 1-215-905-11 METAL OXIDE 10 5% 3W F
R547 1-249-437-11 CARBON 47K 5% 1/4W
R548 1-215-477-00 METAL 220K 1% 1/4W
R549 1-215-473-00 METAL 150K 1% 1/4W
R550 1-215-926-00 METAL OXIDE 33K 5% 3W F
R551 1-249-429-11 CARBON 10K 5% 1/4W
R552 1-249-429-11 CARBON 10K 5% 1/4W
R553 1-215-453-00 METAL 22K 1% 1/4W
R554 1-249-425-11 CARBON 4.7K 5% 1/4W
R601¡ 1-202-847-00 SOLID 560K 20% 1/2W
R602¡ 1-240-262-51 CEMENTED 0.68 5% 10W
R603¡ 1-240-262-51 CEMENTED 0.68 5% 10W
R604¡ 1-215-461-00 METAL 47K 1% 1/4W
R605 1-215-469-00 METAL 100K 1% 1/4W
R606 1-215-423-00 METAL 1.2K 1% 1/4W
R607 1-249-397-11 CARBON 22 5% 1/4W F
R608 1-215-439-00 METAL 5.6K 1% 1/4W
R609¡ 1-216-381-11 METAL OXIDE 0.22 5% 3W F
R610 1-249-417-11 CARBON 1K 5% 1/4W
R611 1-215-469-00 METAL 100K 1% 1/4W
R612 1-215-479-00 METAL 270K 1% 1/4W
R613 1-215-926-00 METAL OXIDE 33K 5% 3W F
R615¡ 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R617¡ 1-219-154-11 FUSIBLE 0.12 10% 1/4W
R619 1-215-929-11 METAL OXIDE 100K 5% 3W F
R621¡ 1-211-874-11 FUSIBLE 0.12 10% 1/2W
R622¡ 1-211-874-11 FUSIBLE 0.12 10% 1/2W
R630 1-249-417-11 CARBON 1K 5% 1/4W
R631¡ 1-249-417-11 CARBON 1K 5% 1/4W
R632 1-215-451-00 METAL 18K 1% 1/4W
R633¡ 1-215-455-00 METAL 27K 1% 1/4W
R635¡ 1-249-417-11 CARBON 1K 5% 1/4W
R636¡ 1-249-417-11 CARBON 1K 5% 1/4W
R637¡ 1-249-429-11 CARBON 10K 5% 1/4W
R638¡ 1-215-463-00 METAL 56K 1% 1/4W
R640 1-215-455-00 METAL 27K 1% 1/4W
R641 1-247-887-00 CARBON 220K 5% 1/4W
R642 1-249-429-11 CARBON 10K 5% 1/4W
R643 1-249-417-11 CARBON 1K 5% 1/4W
R650 1-260-127-11 CARBON 220K 5% 1/2W
R654¡ 1-219-154-11 FUSIBLE 0.12 10% 1/4W
R658¡ 1-247-815-91 CARBON 220 5% 1/4W
R659¡ 1-215-479-00 METAL 270K 1% 1/4W
R660¡ 1-215-435-00 METAL 3.9K 1% 1/4W
R661 1-247-887-00 CARBON 220K 5% 1/4W
R662¡ 1-249-431-11 CARBON 15K 5% 1/4W
R663¡ 1-215-447-00 METAL 12K 1% 1/4W
R666 1-249-441-11 CARBON 100K 5% 1/4W
R668 1-247-895-91 CARBON 470K 5% 1/4W
R670 1-249-417-11 CARBON 1K 5% 1/4W
R671 1-249-417-11 CARBON 1K 5% 1/4W
R672 1-249-403-11 CARBON 68 5% 1/4W
R674 1-249-429-11 CARBON 10K 5% 1/4W
R701 1-216-426-11 METAL OXIDE 82 5% 1W F
R702 1-216-369-00 METAL OXIDE 1 5% 2W F
