REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
VX900T
D
R703 1-216-426-11 METAL OXIDE 82 5% 1W F
R704 1-216-369-00 METAL OXIDE 1 5% 2W F
R705 1-215-429-00 METAL 2.2K 1% 1/4W
R706 1-215-437-00 METAL 4.7K 1% 1/4W
R707 1-247-863-91 CARBON 22K 5% 1/4W
R708 1-215-859-00 METAL OXIDE 22 5% 1W F
R709 1-249-383-11 CARBON 1.5 5% 1/4W F
R710 1-215-436-00 METAL 4.3K 1% 1/4W
R711 1-215-429-00 METAL 2.2K 1% 1/4W
R712 1-215-437-00 METAL 4.7K 1% 1/4W
R713 1-215-429-00 METAL 2.2K 1% 1/4W
R714 1-249-385-11 CARBON 2.2 5% 1/4W
R716 1-215-449-00 METAL 15K 1% 1/4W
R717 1-215-437-00 METAL 4.7K 1% 1/4W
R718 1-216-423-11 METAL OXIDE 27 5% 1W F
R719 1-215-863-11 METAL OXIDE 100 5% 1W F
R723 1-220-827-91 REGISTER 560K 5% 1/2W
R724 1-215-433-00 METAL 3.3K 1% 1/4W
R727 1-249-429-11 CARBON 10K 5% 1/4W
R729 1-249-428-11 CARBON 8.2K 5% 1/4W
R733 1-215-397-00 METAL 100 1% 1/4W
R734 1-215-443-00 METAL 8.2K 1% 1/4W
R735 1-249-421-11 CARBON 2.2K 5% 1/4W
R736 1-215-429-00 METAL 2.2K 1% 1/4W
R737 1-249-417-11 CARBON 1K 5% 1/4W
R738 1-249-441-11 CARBON 100K 5% 1/4W
R740 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R741 1-215-451-00 METAL 18K 1% 1/4W
R742 1-249-397-11 CARBON 22 5% 1/4W F
R744 1-215-437-00 METAL 4.7K 1% 1/4W
R745 1-249-385-11 CARBON 2.2 5% 1/4W
R747 1-249-393-11 CARBON 10 5% 1/4W F
R748 1-215-449-00 METAL 15K 1% 1/4W
R749 1-215-437-00 METAL 4.7K 1% 1/4W
R750 1-215-858-00 METAL OXIDE 15 5% 1W F
R751 1-215-863-11 METAL OXIDE 100 5% 1W F
R752 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-429-11 CARBON 10K 5% 1/4W
R755 1-249-426-11 CARBON 5.6K 5% 1/4W
R759 1-249-377-11 CARBON 0.47 5% 1/4W F
R760 1-249-377-11 CARBON 0.47 5% 1/4W F
R775 1-215-864-00 METAL OXIDE 150 5% 1W F
R801 1-215-413-00 METAL 470 1% 1/4W
R802 1-215-473-00 METAL 150K 1% 1/4W
R804 1-215-461-00 METAL 47K 1% 1/4W
R805 1-249-432-11 CARBON 18K 5% 1/4W
R806 1-249-429-11 CARBON 10K 5% 1/4W
R807 1-249-425-11 CARBON 4.7K 5% 1/4W
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
The components identified by
[[
[[
[ in this manual have been
carefully factory-selected for each set in order to satisfy
regulations regarding X-ray radiation. Should replacement
be required, replace only with the value originally used.
R808 1-215-461-00 METAL 47K 1% 1/4W
R809 1-249-429-11 CARBON 10K 5% 1/4W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-429-11 CARBON 10K 5% 1/4W
R812¡ 1-215-461-00 METAL 47K 1% 1/4W
R813 1-215-437-00 METAL 4.7K 1% 1/4W
R814 1-249-429-11 CARBON 10K 5% 1/4W
R815 1-249-429-11 CARBON 10K 5% 1/4W
R816 1-249-405-11 CARBON 100 5% 1/4W F
R817 1-249-405-11 CARBON 100 5% 1/4W F
R818 1-249-405-11 CARBON 100 5% 1/4W F
R819 1-249-405-11 CARBON 100 5% 1/4W F
R820 1-249-405-11 CARBON 100 5% 1/4W F
R821 1-249-405-11 CARBON 100 5% 1/4W F
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-425-11 CARBON 4.7K 5% 1/4W
R903¡ 1-215-477-00 METAL 220K 1% 1/4W
R906 1-249-413-11 CARBON 470 5% 1/4W
R907 1-247-903-00 CARBON 1M 5% 1/4W
R908 1-219-748-11 CARBON 4.7K 5% 1/2W
R909 1-219-748-11 CARBON 4.7K 5% 1/2W
R910 1-249-405-11 CARBON 100 5% 1/4W F
R911 1-249-397-11 CARBON 22 5% 1/4W F
R913¡ 1-215-445-00 METAL 10K 1% 1/4W
R914¡ 1-215-437-00 METAL 4.7K 1% 1/4W
R915 1-249-417-11 CARBON 1K 5% 1/4W
R917 1-249-385-11 CARBON 2.2 5% 1/4W F
R918 1-249-385-11 CARBON 2.2 5% 1/4W F
R919 1-215-913-11 METAL OXIDE 220 5% 3W F
R920 1-215-913-11 METAL OXIDE 220 5% 3W F
R921¡ 1-214-964-00 METAL 1M 1% 1/4W
R922¡ 1-215-469-00 METAL 100K 1% 1/4W
R923 1-247-891-00 CARBON 330K 5% 1/4W
VARIABLE RESISTOR
RV904¡ 1-241-767-21 RES, ADJ, CERMET 100K
RELAY
RY601¡ 1-755-067-21 RELAY
SPARK GAP
SG901¡ 1-519-422-11 GAP, SPARK
SG902¡ 1-519-422-11 GAP, SPARK
SG903¡ 1-519-422-11 GAP, SPARK
[
