— 50 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
VX900T
TRANSFORMER
T501¡ 1-429-103-11 TRANSFORMER, FERRITE (HDT)
T502 1-411-594-11 INDUCTOR 5MMH
T503 1-433-411-11 TRANSFORMER, FILTER (LCT)
T504 1-426-998-11 TRANSFORMER, FERRITE (HST)
T601¡ 1-431-968-11 TRANSFORMER, CONVERTER (SRT)
T701 1-431-998-11 TRANSFORMER, FERRITE (DFT)
T901¡ 1-453-292-11 FLYBACK TRANSFORMER ASSY, NX-4501//X4E4
T902 1-411-567-31 INDUCTOR 500UH
THERMISTOR
TH600¡ 1-809-827-11 THERMISTOR
THERMISTOR
THP602¡ 1-809-827-11 THERMISTOR, POSITIVE
VARISTOR
VA601¡ 1-810-622-11 VARISTOR
*A-1372-577-A H BOARD, MOUNTED
* 4-068-021-01 HOLDER, LED
CAPACITOR
C2020 1-102-074-00 CERAMIC 0.001MF 10% 50V
CONNECTOR
CN2003* 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
DIODE
D2001 8-719-067-04 DIODE 339VYUGW/R2
RESISTOR
R2011 1-215-449-00 METAL 15K 1% 1/4W
R2012 1-215-437-00 METAL 4.7K 1% 1/4W
R2013 1-215-429-00 METAL 2.2K 1% 1/4W
R2014 1-215-421-00 METAL 1K 1% 1/4W
R2015 1-215-417-00 METAL 680 1% 1/4W
R2016 1-215-413-00 METAL 470 1% 1/4W
R2017 1-215-409-00 METAL 330 1% 1/4W
R2018 1-215-405-00 METAL 220 1% 1/4W
R2019 1-215-431-00 METAL 2.7K 1% 1/4W
R2020 1-249-407-11 CARBON 150 5% 1/4W
R2021 1-249-413-11 CARBON 470 5% 1/4W
SWITCH
S602¡ 1-571-433-21 SWITCH, PUSH (AC POWER)
S2001 1-692-431-21 SWITCH, TACTILE
S2002 1-692-431-21 SWITCH, TACTILE
S2003 1-692-431-21 SWITCH, TACTILE
S2004 1-692-431-21 SWITCH, TACTILE
S2005 1-692-431-21 SWITCH, TACTILE
S2007 1-692-431-21 SWITCH, TACTILE
S2008 1-692-431-21 SWITCH, TACTILE
* A-1343-597-A N BOARD, MOUNTED
CAPACITOR
C1001 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1002 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1003 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1004 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C1005 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1006 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1007 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1009 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C1010 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C1011 1-110-530-11 ELECT CHIP 1000MF 20% 6.3V
C1012 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1013 1-110-530-11 ELECT CHIP 1000MF 20% 6.3V
C1014 1-126-935-11 ELECT 470MF 20% 6.3V
C1015 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1016 1-126-607-11 ELECT CHIP 47MF 20% 4V
C1017 1-126-935-11 ELECT 470MF 20% 6.3V
C1018 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1019 1-126-607-11 ELECT CHIP 47MF 20% 4V
C1020 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1021 1-216-097-91 RES, CHIP 100K 5% 1/10W
C1022 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1023 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1024 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C1025 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C1026 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
H
N
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡
are critical for safety.
Replace only with part number specified.
Note:
D
H
N
To Next Page
