Gateway VX900T User Manual

— 51 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
VX900T
C1027 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1028 1-126-935-11 ELECT 470MF 20% 6.3V
C1029 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1030 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1031 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1033 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1034 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C1035 1-126-235-11 ELECT 100MF 20% 6.3V
C1036 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1037 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1038 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1040 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1042 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1043 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1044 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1046 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1047 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1048 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1049 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C1050 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1052 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1053 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C1054 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C1055 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1056 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1057 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C1059 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C1060 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1061 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
CONNECTOR
CN1003* 1-564-526-11 PLUG, CONNECTOR 11P
CN1004* 1-564-522-11 PLUG, CONNECTOR 7P
DIODE
D1001 8-719-404-50 DIODE MA111-TX
D1002 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
D1003 1-218-772-11 METAL CHIP 680K 0.50% 1/10W
D1017 8-719-404-50 DIODE MA111-TX
D1018 8-719-404-50 DIODE MA111-TX
FERRITE BEAD
FB1003 1-543-960-22 FERRITE
FB1004 1-543-960-22 FERRITE
FB1005 1-543-960-22 FERRITE
FB2101 1-412-911-31 FERRITE
FB2102 1-412-911-31 FERRITE
FB2103 1-412-911-31 FERRITE
FB2104 1-412-911-31 FERRITE
FB2105 1-412-911-31 FERRITE
IC
IC1001 8-759-580-31 IC ST92T175N1B1/JBU
IC1002 8-759-530-55 IC CXD8768Q
IC1003 8-759-420-77 IC PST574CMT-T1
IC1005 8-759-561-53 IC CAT24WC16J-TE13
IC1006 8-759-568-28 IC MC33269ST-33R2
IC1007 8-759-571-91 IC TLV2262IDR
COIL
L1001 1-408-619-31 INDUCTOR 220UH
TRANSISTOR
Q1001 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1002 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1003 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R1000 1-216-296-91 SHORT
R1001 1-216-081-00 RES, CHIP 22K 5% 1/10W
R1003 1-216-033-00 RES, CHIP 220 5% 1/10W
R1004 1-216-033-00 RES, CHIP 220 5% 1/10W
R1005 1-216-033-00 RES, CHIP 220 5% 1/10W
R1006 1-216-033-00 RES, CHIP 220 5% 1/10W
R1007 1-216-033-00 RES, CHIP 220 5% 1/10W
R1009 1-216-033-00 RES, CHIP 220 5% 1/10W
R1010 1-216-033-00 RES, CHIP 220 5% 1/10W
R1011 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1012 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1013 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1014 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1015 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1016 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1017 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R1018 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R1019 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1020 1-216-049-91 RES, CHIP 1K 5% 1/10W
R1021 1-216-129-00 RES, CHIP 2.2M 5% 1/10W
R1022 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R1023 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R1024 1-216-025-91 RES, CHIP 100 5% 1/10W
R1025 1-216-049-91 RES, CHIP 1K 5% 1/10W
N
