GAUI X3 - Support Rods Assembly

Bigger
inner race
內徑較大
Smaller iner race
內徑較小
P.19
Tail case assembly
尾殼組裝
14
M2x5
#842005
M2x5
Bearing 3x6x2.5
W2x3.5x0.5
W3.1x4.6x0.6
Thrust Bearing
3x6x2.8
Bearing
5x8x2.5
x2 pcs
M2x8
#842008
x2 pcs
#216117
1
7
#216341
2
5
#805107
3
3
#216339
4
1
#805103
5
2
#216115
6
6
#805113
7
4
2
M2x8
P2x2.95x3.1
Make sure M2.6x6 screw is secured with glue and tightened with moderate/proper force.
Do not over-tighten screw and strip it or it may become a flight safety risk.
W5.1x7x0.7
8.0
5.0
M2x5螺絲請確實上膠並適當鎖緊，不可硬鎖以避免造成螺絲受損，影響飛行安全性。
適當鎖緊M2x8螺絲。
Tighten properly
M2x8 screws
