GAUI X5 - Parts List of Fuselage

26
GAUI
TAI SHIH HOBBY CORPORATION
Parts List of Fuselage
機身體分解圖零件表
8
208344 X5 Canopy Posts(Silver anodized)(39.5mm)x2 (42.5mm)x2
X5 CNC艙罩支柱(電鍍亮銀)(39.5mm)x2
(42.5mm)x2
208361 X5 CNC Boom Clamps (Silver anodized)
X5 CNC尾管固定座(亮銀)
208362 X5 Tail Supporter Pipes(Silver anodized)
X5 CNC支撐桿(亮銀)
208370 X5 Skid Set (Silver anodized)
X5 滑橇組(亮銀)
208382 Mast Collar Set
主軸輪擋
208400
Alu Square Post with 3mm middle hole (5x5x23.5mm) and
Round Post (3x4.8x23mm)
方鋁柱附3mm貫穿孔(5x5x23.5mm)及
圓鋁柱(3x4.8x23mm)
208402
Alu Square Post with 3mm thread hole (5x5x23.5mm) and
Round Post (3x4.8x23mm)
方鋁柱附3mm牙孔(5x5x23.5mm)及
圓鋁柱(3x4.8x23mm)
208707 X5 Right CF Frame with Metal parts(1.6mm)
X5 黑玻纖機身側板含附件(右)(1.6mm)
208708 X5 Left Fiber Frame(1.6mm)
X5 黑玻纖側板(左)(1.6mm)
208709 X5 Stiffening Plates and Mounts for electronics(1.6mm)
X5 黑玻纖陀螺儀座及電池座及強化板組
(1.6mm)
208785 Spacer (3x6x4) x8pcs
襯套(P-3x6x4)x8pcs
208855 Socket Countersunk Screw - Black (M3x6)x10pcs
內六角皿頭螺絲包-黑色(M3x6)x10個
208856 Socket Head Button Screw - Black (M3x4)x10pcs
半圓頭內六角螺絲包-黑色(M3x4)x10個
208858 Socket Head Button Screw - Black (M3x6)x20pcs
半圓頭內六角螺絲包-黑色(M3x6)x20個
208862 Socket Head Button Screw - Black (M3x14)x10pcs
半圓頭內六角螺絲包-黑色(M3x14)x10個
208863 Socket Head Button Screw - Black (M3x18)x10pcs
半圓頭內六角螺絲包-黑色(M3x18)x10個
208864
Semi-threaded Socket Head Cap Screw -
Black (M3x16)x10pcs
半牙內六角螺絲包-黑色(M3x16)x10個
208865 Socket Set Screw (M3x3)x10pcs
內六角止付螺絲包-黑色(M3x3)x10個
208871 Socket Head Cap Screw - Black (M3x6)x10pcs
內六角螺絲包-黑色(M3x6)x10個
208872 Socket Head Cap Screw - Black (M3x10)x10pcs
內六角螺絲包-黑色(M3x10)x10個
208890 Canopy Damper x 6pcs
艙罩墊圈x6個
208970 X5 Brace Set
X5 支撐架組
