48
Press the Belt Tensioning Plate down with both
hands, where indicated, until it locks into place.
The orange Locking Lever will rotate to the
CLOSE position automatically when the Plate is
locked.
If the Belt Tensioning Plate does not lock, try
loosening the vehicle belt slightly.
Grab the Base at the Belt Guides and pull from
side to side and front to back to make sure it is
installed correctly. The Base should not move
more than 1 inch (2.5 cm) in any direction.
If the Base moves too much, open the Belt
Tensioning Plate and remove a little more slack
from the vehicle belt, close Plate and recheck.
After this, if the Base still moves too much, you
may need to try a dierent vehicle seat location
or installation method, or both.
Automatic
DO NOT turn
7
8
INSTALLING THE BASE USING A LAP BELT ONLY
7
8
