GBC 17P User Manual

Page 3-1
ProCut 17P – Installation and Operating Instructions
Model
ProCut 17P
Control
Programmable
Minimum Cut Length
1.96 in. (50 mm)
Maximum Cut Length
17.71 in. (449.8 mm)
Maximum Cut Thickness
1.75 in. (45 mm)
Maximum Cut Width
17.5 in. (445 mm)
Dimensions:
• Width
• Height
• Depth
• Work Table Height
26.00 in. (660.4 mm)
48.00 in. (1219.2 mm)
36.50 in. (927.1 mm)
38.50 in. (977.9 mm)
Weight
298 lbs. (135 kg).
Electrical Requirements:
• Voltage
• Current
• Power
• Receptacle
115-120V 60 Hz
7A
1000 Watts
NEMA 5-15R
Cycle Time
Operating time = 7 seconds
Rest time = 3 seconds
Paper Press Method/Clamp
Automatic
Paper Pusher/Back Gauge
Automatic
3. sPecIFIcatIons
W
i
d
t
h
De
pt
h
Height
Figure 1. ProCut 17P Dimensions

GBC 17P Specifications

General

Brand	GBC
Model	17P
Category	Paper Cutters
Language	English
