F-60 Operation and Maintenance Manual

Maintenance and Troubleshooting

4-5

/XEULFDWLRQ

Tools required:

•

" hex wrench

• High temperature grease or lithium grease

• Grease gun

To lubricate the laminator:

WARNING

1. Remove the drive and control side cabinet covers

using the

" hex wrench by removing the eight

screws holding each cover in place. Gently rotate

the cover around the clutch knob to allow access to

the lubrication points.

2. Using the grease gun, lubricate each grease fitting

with one squirt of high temperature grease.

3. Lubricate the chain using a soft cloth and automo-

tive oil.

4. Replace the cabinet covers, close the safety shields

and reapply power to the laminator.

&RQWDFWLQJ 7HFKQLFDO 6XSSRUW

For machine parts and technical service in North

America, please call: 1-800-790-7787.

Please provide

serial number when calling for service.

In Europe,

please call: +44 (0) 1844 202 440 or fax: +44 (0) 1844

202 441.

For film and application questions in North America,

please call 1-800-236-8843. In Europe, please call: +44

(0) 1844 202 440 or fax: +44 (0) 1844 202 441.

Do not lubricate the laminator when it is hot. You

can be burned.

Remove and lockout power from the laminator

while you are performing this procedure. You

could be severely shocked, electrocuted, or get

your fingers caught in the drive mechanisms.
