F-60 Operation and Maintenance Manual
6HFWLRQ6SHFLILFDWLRQV3DUWVDQG
6FKHPDWLF
Table 6-1: F-60 Laminator Specifications
Table 6-2: Replacement Parts
Dimensions
(L x D x H)
Uncrated: 80" x 33" x 57"
(202 x 84 x 145 cm)
Crated: 90" x 44" x 68"
(202 x 84 x 145 cm)
Weight Uncrated: 1200 lbs (544 kg)
Crated :1700 lbs (771 kg)
Laminating Rolls 64" (163 cm) roll face with a
high release surface, upper and
lower rolls internally heated.
Laminating Material Uses pressure sensitive materi-
als up to 62 inches (158 cm)
wide and hot/heat activated
materials up to 61 inches (155
cm) wide on a 3-inch (7.6 cm)
inside diameter core, maxi-
mum roll diameter of 10 inches
(25.4 cm).
Laminating Speeds 0 to 15 fmp (0 to 4.57 mpm)
with variable speed, reversible
action at slow speed (less than 3
ft/min (1 m/min)), start and
stop controlled either through
the instrument panel or with the
variable speed footswitch
Heating Capable of operating tempera-
tures of up to 270 ºF (132 ºC).
Safety Features • Redundant circuit pro-
tected safety shielding
• Mechanical shielding on
infeed
• Slow mode (1 m/min) for
all reverse operations with
beeping warning alarm
• Four emergency stop but-
tons
• Pull rolls contained in an
enclosure to prevent injury
Installation
Requirement
55A single phase, 220/230/240
VAC or, in Europe, 3 Phase,
240/400 VAC with 25 Amps
per phase.
Part
Number
Description Recommended
Quantity
001-374 Assembly, Force
Gauge PCB
1
001-505 Assembly, Force
Sensor
1
001-515 Assembly, Control
PCB
1
186-200 Fuse, SB, 3AG, 3A 3
214-313 Switch, Palm, E-stop 1
230-007 Temperature Control 1
425-003 Motor 1
690-059 Roll, Rubber 1
026-004 Flanged Bearing,
Plastic 5/8
2
189-031 Heater, Round 1
230-006 IR Sensor 1
860-014 Tube, Rewind Brake 2
214-005 Microswitch, Safety,
Interlock
1
186-135 Fuse, 250V, 20A,
Ceramic
1
690-052 Roll, Pull, Upper 1
690-053 Roll, Pull, Lower 1
