GCAN-PLC user manual
7. Technical specifications
PLC Parameters
Programming environment
OpenPCS software
Flash
（
Program storage
）
32M bytes
SRAM
（
Data storage
）
16M bytes
User data store
2k bytes
Run-Time system
A
PLC mission
PLC cycle time
1000 instructions need about 1ms（ignore I/O circulation
and GC-bus）
Programming
online
modified
Not support
Programming language
implementation standard
IEC 61131-3
Programming language
SFC（Sequentialfunctionchart）、LD（Ladderdiagram）、
FBD（Functionblock） 、ST（Structuredtext） 、IL
（
Instruction List
）
Local I/O
None, need extend GC series module
Extend terminal
quantity
module
Up to 32 modules
Digital I/O signal
256 input/output
Analog I/O signal
64 input/output
Configuration mode
automatic configuration
Real-time clock
Built-in
Floating point operations
Support
Communication interface
Communication interface
One-channel CAN interface, one-channel Ethernet
interface, one-channel RS232/RS485 interface
CANopen protocol
master/slave function
Support
Modbus RTU/TCP protocol
master/slave function
Support
Electrical parameters
Power
24V DC（-15%/+20%）
Input current
70mA+
（
total GC-bus current
）
/maximum2.5A
Starting current
About 2.5 times continuous current
Fuse capacity
≤10A
Power contacts
Maximum 24V DC/maximum 10A
Electrical isolation
1500 Vrms
Environmental testing
Working temperature
-40℃~+85℃
Working humidness
95%RH, without condensation
