1. STANDARD UPGRADE PACKING LIST AND
RETURN LIST
1.1 Standard Upgrade Packing List
Standard Upgrade HFR hardware package kit includes:
1. Upgrade package hardware checklist and software upgrade manual
2. NEW IMB
3. Cover plate for projector type
4. RJ45 Audio cable x 2
5. Traditional audio converter (RJ45 x 2 to 25pin female)
6. RJ45 GPIO cables x 4 (10 M)
7. RJ45 network cables x 1 (3 M)
8. New server s/n Label
9. Packaging boxes will be used for returned items after upgrade
10. An additional gigabit network card
11. Return item checklist
Note: RJ45 network cables should be of good quality CAT6 cables to guarantee proper network data
transfer between the server and HFR IMB. Network cables with poor quality can cause video/audio jitter
during playback.
1.2 Standard Upgrade Return List
For SX-2000 upgrade, the following items should be returned:
1. 1 x Original IMB + 1 x PCIe subcard
2. Coverplate for projector type
3. PCIe cable (3/5/7M)
4. Old server s/n Label (SX-2000)
5. Boxes for return items
6. Return item checklist
2. UPGRADE INFORMATION
ServerID upgrade
upgrade-serverID_Axxxxx…tgz.enc
Upgrade package1
Upgrade package2
upgrade-SX2000AR-step2-
[YYYYMMDD].tgz.enc
upgrade-SX2000AR-buildxx-
[YYYYMMDD]-incr.tgz.enc
Upgrade should be applied on
7.81 to 7.83
Upgrade estimated total time
15 to 20 mins
NOTE: If the server is already upgraded to SX-2000(A/T)R, (with HFR IMB), then please follow
Section 6 Apply Upgrade Package 2 to update to the latest build (SKIP Sections 5.1 and 5.2).
