FEATURE INFORMATION
6-2
Cause of Event Displayed Message
1) Phase A Timed O/C Trip PH-A TIME O/C T
2) Phase B Timed O/C Trip PH-B TIME O/C T
3) Phase C Timed O/C Trip PH-C TIME O/C T
4) Ground Timed O/C Trip GND TIMED O/C T
5) Phase A Inst Trip PH-A INST O/C T
6) Phase B Inst Trip PH-B INST O/C T
7) Phase C Inst Trip PH-C INST O/C T
8) Ground Inst Trip GND INST O/C T
9) Overvoltage Trip OVERVOLTAGE T
10) Undervoltage Trip UNDERVOLTAGE T
11) Analog Input Trip ANALOG INPUT T
12) External Trip #1 EXT. TRIP #1 T
13) External Trip #2 EXT. TRIP #2 T
14) External Trip #3 EXT. TRIP #3 T
15) External Trip #4 EXT. TRIP #4 T
16) Power Factor Trip P/F TRIP T
17) Frequency Trip FREQ. TRIP T
18) Phase O/C Alarm PH O/C ALARM A
19) Ground O/C Alarm GND O/C ALARM A
20) Overvoltage Alarm OVERVOLTAGE A
21) Undervoltage Alarm UNDERVOLTAGE A
22) Analog Input Alarm ANALOG INPUT A
23) Accumulated KA2 Alarm ACCUM KA A
24) Definite Time Alarm 1 SWITCH ALARM1 A
25) Definite Time Alarm 2 SWITCH ALARM2 A
26) Amps Demand Alarm AMPS DEMAND A
27) KW Demand Alarm KW DEMAND A
28) KVAR Demand Alarm KVAR DEMAND A
29) Power Factor Alarm P/F ALARM A
30) Frequency Alarm FREQ. ALARM A
31) Breaker Discepancy Alarm BRK DISCRPNCY A
32) Trip Coil Alarm TRIP COIL A
33) MTM Communications Alarm MTM COMM ALM A
34) Phase O/C Alarm Reset PH OC ALM RST O
35) Ground O/C Alarm Reset GD OC ALM RST O
36) Overvoltage Alarm Reset OV ALARM RST O
37) Undervoltage Alarm Reset UV ALARM RST O
38) Analog Input Alarm Reset AI ALARM RST O
39) Definite Time Alarm1 Reset SW ALM1 RST O
40) Definite Time Alarm2 Reset SW ALM2 RST O
41) Breaker Discrepancy Alarm Reset BRK ALM RST O
42) Access Jumper Installed AC JUMPER INS O
43) Access Jumper Removed AC JUMPER REM O
44) Block Inst Trip Enabled INST-BLOCK EN O
45) Block Inst Trip Disabled INST-BLOCK DI O
46) Block Timed O/C Trips Enabled TIMED-BLK ENB O
47) Block Timed O/C Trips Disabled TIMED-BLK DIS O
48) Curve Adjust Enabled CURVE ADJ. EN O
49) Curve Adjust Disabled CURVE ADJ. DI O
50) Illegal Setpoint Access ILL-ACCESS O
51) System Manual Reset MANUAL RESET O
52) Control Switch to Remote SWITCH REMOTE O
53) Control Switch to Local SWITCH LOCAL O
