FEATURE INFORMATION
565/575 MEMORY MAP (REVISION E2.73)
ADDRESS GROUP DESCRIPTION RANGE STEP UNITS SCALE FORMAT FACTORY
(DEC) (HEX) CODE DEFAULT
Actual Values - READ ONLY
0090 005A RESERVED
:: :
0091 005B RESERVED
0040 0028 VOLTAGE VOLTS PHASE A-X 0 TO 431.25 --- KVOLTS 0.01 F14 ---
0041 0029 VOLTS PHASE B-X 0 TO 431.25 --- KVOLTS 0.01 F14 ---
0042 002A VOLTS PHASE C-X 0 TO 431.25 --- KVOLTS 0.01 F14 ---
0043 002B FREQUENCY OF FEEDER --- --- Hz 0.01 F14 ---
0092 005C SEE ACTUAL VALUES DEMAND & METERING DATA
:: :
0114 0072 SEE ACTUAL VALUES DEMAND & METERING DATA
0115 0073 EVENT RESERVED
0116 0074 NO. OF EVENTS: 0 TO 40 --- --- 1.00 F14 ---
0117 0075 VIEW EVENTS? (RESERVED)
0118 0076 RESERVED
0119 0077 PRINT EVENTS? (RESERVED)
0120 0078 CLEAR EVENTS? (RESERVED)
0121 0079 EVENTS CLEARED LAST: --- --- --- --- F13 ---
0092 005C DEMAND DATA PH-A PEAK DEMAND --- --- AMPS 0.01 F12 ---
0094 005E PH-B PEAK DEMAND --- --- AMPS 0.01 F12 ---
0096 0060 PH-C PEAK DEMAND --- --- AMPS 0.01 F12 ---
0098 0062 CLEAR AMP DEMAND DATA? (RESERVED)
0099 0063 DATA CLEARED LAST: --- --- --- --- F13 ---
0101 0065 PEAK KW DEMAND --- --- KW 1.00 F14 ---
0102 0066 CLEAR KW DEMAND DATA? (RESERVED)
0103 0067 KW DEMAND DATA CL'D: --- --- --- --- F13 ---
0105 0069 PEAK KVAR DEMAND --- --- KVAR 1.00 F14 ---
0106 006A CLEAR KVAR DEM'D DATA? (RESERVED)
0107 006B KVAR DEMAND DATA CL'D: --- --- --- --- F13 ---
0109 006D METERING KW AND KVAR POWER SIGNS --- --- --- --- F16 ---
0110 006E DATA POWER FACTOR --- --- --- 0.01 F17 ---
0111 006F FREQUENCY MTM --- --- Hz 0.10 F14 ---
0112 0070 REAL POWER 0 T0 +/- 65535 --- KW 1.00 F18 ---
0113 0071 REACTIVE POWER 0 T0 +/- 65535 --- KVAR 1.00 F18 ---
0114 0072 REAL ENERGY USED --- --- MWHRS 1.00 F14 ---
0123 007B RESERVED
:: :
0255 00FF RESERVED
Setpoints - READ/WRITE
0256 0100 USER LEVEL USER LEVEL 0 or 1 - - - F19 1
0257 0101 SECURITY FEATURE 0 or 1 - - - F20 1
0258 0102 SETPOINT ACCESS 0 or 1 - - - F20 0
0259 0103 RESERVED
0260 0104 PHASE CURRENT PHASE CT RATING PRIMARY 10 - 5000 5 AMPS 1.00 F14 100
0261 0105 SEE SETPOINTS PHASE CURRENT GROUP
0262 0106 PHASE TIMED O/C PICKUP 25 - 250 1 %CT 1.00 F14 100
0261 0105 PHASE O/C CURVE SHAPE (565) or PH. O/C CURVE 1 SHAPE (575) 0 - 7 - - - F21 3
0263 0107 PHASE O/C TIME DIAL (565) or PHASE O/C TIME DIAL 1 (575) 1 - 32 1 - 1.00 F14 1
0264 0108 PHASE O/C TRIP RELAY 0 - 6 - - - F22 0 (565), 1 (575)
0265 0109 PHASE O/C ALARM 0 or 1 - - - F20 1
0266 010A PHASE O/C ALARM LEVEL 0.5 - 3.0 0.1 X P/U 0.10 F14 1.5
0267 010B PHASE O/C ALARM DELAY 1 - 255 1 SEC 1.00 F14 1
0268 010C PHASE O/C ALARM RELAY 0 - 3 - - - F23 0 (565), 1 (575)
0269 010D PHASE INST TRIPS (565) or PHASE HISET INST TRIPS (575) 0 or 1 - - - F20 0
0270 010E PHASE INST TRIP LEVEL (565) or PHASE HISET INST TRIP LEVEL (57
5
1.0 -18.0 0.1 X P/U 0.10 F14 3.0
0271 010F PHASE INST TRIP DELAY (565) or PHASE HISET INST DELAY (575) 0 - 40 1 CYC 1.00 F14 0
0272 0110 PHASE INST TRIP RELAY (565) or PHASE HISET INST RELAY (575) 0 - 6 - - - F22 0 (565), 1 (575)
0273 0111 (575 Only) PH AUTOBLK INST HISET 0 or 1 - - - F20 1
0274 0112 (575 Only) PH AUTOBLK HISET AFTER RECL.# 1 - 4 1 - 1.00 F14 4
0275 0113 (575 Only) PHASE LOSET INST TRIPS 0 or 1 - - - F20 0
0276 0114 (575 Only) PHASE LOSET INST TRIP LEVEL 1.0 - 18.0 0.1 X P/U 0.10 F14 2.0
0277 0115 (575 Only) PHASE LOSET INST DELAY 0 - 40 1 CYC 1.00 F14 0
0278 0116 (575 Only) PHASE LOSET INST RELAY 0 - 2 - - - F22 1
0279 0117 (575 Only) PH AUTOBLK INST LOSET 0 or 1 - - - F20 1
0280 0118 (575 Only) PH AUTOBLK LOSET AFTER RECL.# 1 - 4 1 - 1.00 F14 4
