FEATURE INFORMATION
565/575 MEMORY MAP (REVISION E2.73)
ADDRESS GROUP DESCRIPTION RANGE STEP UNITS SCALE FORMAT FACTORY
(DEC) (HEX) CODE DEFAULT
Actual Values - READ ONLY
0281 0119 TRIP TIME (SEC) (RESERVED)
0282 011A RESERVED
:: :
0299 012B RESERVED
0300 012C GROUND CURRENT GROUND CURRENT SENSING 0 or 1 - - - F20 0
0301 012D SENSING SYSTEM 0 or 1 - - - F24 0
0302 012E CT RATIO PRIMARY 10 - 5000 5 AMPS 1.00 F14 100
0303 012F SEE SETPOINTS GROUND CURRENT GROUP
0304 0130 GROUND TIMED O/C PICKUP 5 - 150 1 % CT 1.00 F14 40
0303 012F GND O/C CURVE SHAPE (565) or GND O/C CURVE 1 SHAPE (575) 0 - 7 - - - F21 3
0305 0131 GROUND O/C TIME DIAL (565) or GROUND O/C TIME DIAL 1 (575) 1 - 32 1 - 1.00 F14 1
0306 0132 GROUND O/C RELAY 0 - 6 - - - F22 0 (565), 1 (575)
0307 0133 GROUND O/C ALARM 0 or 1 - - - F20 1
0308 0134 GND O/C ALARM LEVEL 0.5 - 3.0 0.1 X P/U 0.10 F14 1.5
0309 0135 GND O/C ALARM DELAY 1 - 255 1 SEC 1.00 F14 1
0310 0136 GND O/C ALARM RELAY 0 - 3 - - - F23 0 (565), 1 (575)
0311 0137 GROUND INST TRIPS (565) or GND HISET INST TRIPS (575) 0 or 1 - - - F20 0
0312 0138 GND INST TRIP LEVEL (565) or GND HISET INST TRIP LEVEL (575) 1.0 - 7.0 0.1 X P/U 0.10 F14 3.0
0325 0145 GND INST TRIP 2 LEVEL (565) or GND HISET INST TRIP2 LEVEL (575 1.0 - 18.0 0.1 X P/U 0.10 F14 3.0
0313 0139 GND INST TRIP DELAY (565) or GND HISET INST DELAY (575) 0 - 40 1 CYC 1.00 F14 0
0314 013A GND INST TRIP RELAY (565) or GND HISET INST RELAY (575) 0 - 6 - - - F22 0 (565), 1 (575)
0315 013B (575 Only) GND AUTOBLK INST HISET 0 or 1 - - - F20 1
0316 013C (575 Only) GND AUTOBL HISET AFTER RECL.# 1 - 4 1 - 1.00 F14 4
0317 013D (575 Only) GND LOSET INST TRIPS 0 or 1 - - - F20 0
0318 013E (575 Only) GND LOSET INST TRIP LEVEL 1.0 - 7.0 0.1 X P/U 0.10 F14 3.0
0326 0146 (575 Only) GND LOSET INST TRIP2 LEVEL 1.0 - 18.0 0.1 X P/U 0.10 F14 3.0
0319 013F (575 Only) GND LOSET INST DELAY 0 - 40 1 CYC 1.00 F14 0
0320 0140 (575 Only) GND LOSET INST RELAY 0 - 2 - - - F22 1
0321 0141 (575 Only) GND AUTOBLK INST LOSET 0 or 1 - - - F20 1
0322 0142 (575 Only) GND AUTOBL LOSET AFTER RECL.# 1 - 4 1 - 1.00 F14 4
0323 0143 TRIP TIME (SEC) (RESERVED)
0324 0144 RESERVED
0325 0145 SEE SETPOINTS GROUND CURRENT GROUP
:: :
0326 0146 SEE SETPOINTS GROUND CURRENT GROUP
0327 0147 RESERVED
:: :
0328 0148 RESERVED
0329 0149 CONFIGURATION SEE SETPOINTS CONFIGURATION GROUP
:: :
0339 0153 SEE SETPOINTS CONFIGURATION GROUP
0340 0154 SET TIME - - - - F13 -
0342 0156 SET DATE - - - - F13 -
0344 0158 RESET BLOCKED 0 - 8 - - - F26 0
0345 0159 BLOCK INST TRIPS 0 - 8 - - - F26 0
0346 015A BLOCK TIMED O/C TRIPS 0 - 8 - - - F26 0
0339 0153 BLOCK GND TRIPS 0 - 8 - - - F26 0
0347 015B DEFINITE TIME # 1 ALARM 0 - 8 - - - F26 0
0348 015C DEFINITE TIME #1 DELAY 1 - 255 1 SEC 1.00 F14 1
0349 015D DEFINITE TIME #1 RELAY 0 - 3 - - - F23 1 (565), 2 (575)
0373 0175 DEFINITE TIME # 2 ALARM 0 - 8 - - - F26 0
0374 0176 DEFINITE TIME #2 DELAY 1 - 255 1 SEC 1.00 F14 1
0375 0177 DEFINITE TIME #2 RELAY 0 - 3 - - - F23 1 (565), 2 (575)
0350 015E EXTERNAL TRIP #1 (565) or EXTERNAL TRIP (575) 0 - 8 - - - F26 0
0351 015F EXTERNAL TRIP #1 RELAY (565) or EXTERNAL TRIP RELAY (575) 0 - 6 - - - F22 3 (565), 1 (575)
0329 0149 (565 Only) EXTERNAL TRIP #1 DELAY 0 - 60 1 CYC 1.00 F14 0
0352 0160 SEE SETPOINTS CONFIGURATION GROUP
:: :
0362 016A SEE SETPOINTS CONFIGURATION GROUP
0363 016B RESERVED
:: :
0364 016C RESERVED
0365 016D SEE SETPOINTS CONFIGURATION GROUP
:: :
0375 0177 SEE SETPOINTS CONFIGURATION GROUP
0376 0178 EXTERNAL TRIP #2 (565) or RECLOSABLE TRIP (575) 0 - 8 - - - F26 0
0377 0179 EXTERNAL TRIP #2 RELAY (565) or RECLOSABLE TRIP RELAY (575) 0 - 6 - - - F22 3 (565), 1 (575)
0330 014A (565 Only) EXTERNAL TRIP #2 DELAY 0 - 60 1 CYC 1.00 F14 0
0378 017A EXTERNAL TRIP #3 (565) or PROGRAMMABLE TRIP (575) 0 - 8 - - - F26 0
0379 017B EXTERNAL TRIP #3 RELAY (565) or PROGRAMABLE TRIP RELAY (575
0 - 6 - - - F22 3 (565), 1 (575)
6-13
