FEATURE INFORMATION
565/575 DATA FORMATS (REVISION E2.73)
FORMAT APPLICABLE BITS DEFINITION
CODE
0000 0000 0000 0011 (BIN) or 0003 (HEX) 03 (DEC) = SW. 3
0000 0000 0000 0100 (BIN) or 0004 (HEX) 04 (DEC) = SW. 4
0000 0000 0000 0101 (BIN) or 0005 (HEX) 05 (DEC) = SW. 5
0000 0000 0000 0110 (BIN) or 0006 (HEX) 06 (DEC) = SW. 6
0000 0000 0000 0111 (BIN) or 0007 (HEX) 07 (DEC) = SW. 7
0000 0000 0000 1000 (BIN) or 0008 (HEX) 08 (DEC) = SW. 8
F27
16 bits
PROGRAMMABLE SWITCH TRIP OPERATION MODE SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Non-Recl. (575)
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Recl. (575)
F28
16 bits
EXTERNAL SWITCH CONFIGURATION/STATUS
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Open
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Closed
F29
16 bits
TRIP RELAY OPERATION MODE SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Latched (565)
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Pulsed (565)
F30
16 bits
AUXILIARY RELAY OPERATION MODE SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Latched
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Unlatched
0000 0000 0000 0010 (BIN) or 0002 (HEX) 02 (DEC) = Pulsed
F31
16 bits
EVENT PRINTING OPERATION MODE SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Offline
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Online
F32
32 bits
ULONG (SPECIAL FOR ANALOG IN ALARM/TRIP THRESHOLDS)
XX XX 00 00 (HEX) Lower Address Contains The Most Significant 16 bits
00 00 XX XX (HEX) Upper Address Contains The Least Significant 16 bits
Example:
XXXXXX (DEC) * Scaling Factor = Result
Use The Following To Determine The Scaling Factor:
(1) [(Maximum Current Scale Value - Minimum Current Scale Value) < 40.89] = 0.01
(2) [(Maximum Current Scale Value - Minimum Current Scale Value) > 40.88]
And
[(Maximum Current Scale Value - Minimum Current Scale Value) < 408.80] = 0.1
(3) [(Maximum Current Scale Value - Minimum Current Scale Value > 408.79)] = 1.0
Note: Only Reading The Upper Address Will Return Zero, As This Register Is Non-existent
F33
16 bits
ANALOG OUT PARAMETER SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Phase A Current
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Phase B Current
0000 0000 0000 0010 (BIN) or 0002 (HEX) 02 (DEC) = Phase C Current
0000 0000 0000 0011 (BIN) or 0003 (HEX) 03 (DEC) = Ground Current
0000 0000 0000 0100 (BIN) or 0004 (HEX) 04 (DEC) = Phase A-X Voltage
0000 0000 0000 0101 (BIN) or 0005 (HEX) 05 (DEC) = Phase B-X Voltage
0000 0000 0000 0110 (BIN) or 0006 (HEX) 06 (DEC) = Phase C-X Voltage
0000 0000 0000 0111 (BIN) or 0007 (HEX) 07 (DEC) = Feeder Frequency
0000 0000 0000 1000 (BIN) or 0008 (HEX) 08 (DEC) = External Analog Select
F34
16 bits
ANALOG OUT RANGE SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = 0 - 1 mA
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = 4 - 20 mA
F35
16 bits
COMMUNICATION BAUDRATE SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = 1200 Baud
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = 2400 Baud
0000 0000 0000 0010 (BIN) or 0002 (HEX) 02 (DEC) = 4800 Baud
0000 0000 0000 0011 (BIN) or 0003 (HEX) 03 (DEC) = 9600 Baud
F36
16 bits
OUTPUT CONTACT TEST SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Trip
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Aux 1
0000 0000 0000 0010 (BIN) or 0002 (HEX) 02 (DEC) = Aux 2
0000 0000 0000 0011 (BIN) or 0003 (HEX) 03 (DEC) = Aux 3
0000 0000 0000 0100 (BIN) or 0004 (HEX) 04 (DEC) = All (565), Aux 4 (575)
0000 0000 0000 0101 (BIN) or 0005 (HEX) 05 (DEC) = Block Tap Change (575)
0000 0000 0000 0110 (BIN) or 0006 (HEX) 06 (DEC) = All (575)
F37
16 bits
BREAKER OPEN/CLOSE STATUS
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = No
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Yes
F38
16 bits
ANALOG SELECT STATUS
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Off
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = On
F39
16 bits
LOCAL/REMOTE STATUS
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Local
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Remote
F40
16 bits
VT CONNECTION TYPE SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = None
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Wye
6-27
