FEATURE INFORMATION
565/575 DATA FORMATS (REVISION E2.73)
FORMAT APPLICABLE BITS DEFINITION
CODE
0000 0000 0000 0010 (BIN) or 0002 (HEX) 02 (DEC) = Open Delta
0000 0000 0000 0011 (BIN) or 0003 (HEX) 03 (DEC) = Delta/Wye
F41
16 bits
MTM CT SELECTION
0000 0000 0000 0000 (BIN) or 0000 (HEX) 00 (DEC) = Common
0000 0000 0000 0001 (BIN) or 0001 (HEX) 01 (DEC) = Separate
F42
40 bytes
EVENT RECORD DATA
Data Byte 00 Unused
Data Byte 01 :
Data Byte 02 :
Data Byte 03 Cause Of Event
(See Accompanying Cause Of Event Table)
Data Byte 04 Time Of Event (See F13)
Data Byte 05 :
Data Byte 06 :
Data Byte 07 :
Data Byte 08 Date Of Event
(See F13)
Data Byte 09 :
Data Byte 10 :
Data Byte 11 :
Data Byte 12 Phase A Current
(See Accompanying Number Format Description)
Data Byte 13 :
Data Byte 14 :
Data Byte 15 :
Data Byte 16 Phase B Current
(See Accompanying Number Format Description)
Data Byte 17 :
Data Byte 18 :
Data Byte 19 :
Data Byte 20 Phase C Current
(See Accompanying Number Format Description)
Data Byte 21 :
Data Byte 22 :
Data Byte 23 :
Data Byte 24 Ground Current
(See Accompanying Number Format Description)
Data Byte 25 :
Data Byte 26 :
Data Byte 27 :
Data Byte 28 Voltage A-X
(See Accompanying Number Format Description)
Data Byte 29 :
Data Byte 30 :
Data Byte 31 :
Data Byte 32 Voltage B-X
(See Accompanying Number Format Description)
Data Byte 33 :
Data Byte 34 :
Data Byte 35 :
Data Byte 36 Voltage C-X
(See Accompanying Number Format Description)
Data Byte 37 :
Data Byte 38 :
Data Byte 39 :
CAUSE OF EVENT TABLE
(*) = Only Those Events Marked With An Asterisk Will Have Their Current And Voltage
Parameters Recorded.
01
HEX
(*) Phase A Timed Overcurrent Trip (565, 575)
02
HEX
(*) Phase B Timed Overcurrent Trip (565, 575)
03
HEX
(*) Phase C Timed Overcurrent Trip (565, 575)
04
HEX
(*) Ground Timed Overcurrent Trip (565, 575)
05
HEX
(*) Phase A Instantaneous Overcurrent Trip (565)
06
HEX
(*) Phase B Instantaneous Overcurrent Trip (565)
07
HEX
(*) Phase C Instantaneous Overcurrent Trip (565)
08
HEX
(*) Ground Instantaneous Overcurrent Trip (565)
09
HEX
(*) Phase A Hiset Instantaneous Trip (575)
0A
HEX
(*) Phase B Hiset Instantaneous Trip (575)
0B
HEX
(*) Phase C Hiset Instantaneous Trip (575)
0C
HEX
(*) Ground Hiset Instantaneous Trip (575)
0D
HEX
(*) Phase A Loset Instantaneous Trip (575)
0E
HEX
(*) Phase B Loset Instantaneous Trip (575)
0F
HEX
(*) Phase C Loset Instantaneous Trip (575)
10
HEX
(*) Ground Loset Instantaneous Trip (575)
11
HEX
(*) Overvoltage Trip (565, 575)
12
HEX
(*) Undervoltage Trip (565, 575)
13
HEX
Analog Input Trip (565, 575)
14
HEX
External Trip #1 (565)
15
HEX
External Trip #2 (565)
6-28
