4-11
Location Message Line Description
Messages A 6.1 to 6.9 will only appear if voltage sensing has been enabled in setpoints mode.
A 6.1
ACTUAL VALUES
VOLTAGE
The actual values page 6 header. This page gives values of the voltage and
frequency of the three phase feeder being monitored by the 565/575
Relay.
Messages A 6.2 to 6.4 will only appear if an Open Delta system is chosen in Setpoints mode.
A 6.2
VOLTAGE A-B
4.16 kV
The voltage between phases A and B of the feeder being monitored by the
565/575 Relay.
A 6.3
VOLTAGE B-C
4.16 kV
The voltage between phases B and C of the feeder being monitored by the
565/575 Relay.
A 6.4
VOLTAGE C-A
4.16 kV
The voltage between phases C and A of the feeder being monitored by the
565/575 Relay.
Messages A 6.5 to 6.7 will only appear if a Wye system is chosen in setpoints mode.
A 6.5
VOLTAGE A-N
2.30 kV
The voltage between phase A and the neutral line of the feeder being
monitored by the 565/575 Relay.
A 6.6
VOLTAGE B-N
2.30 kV
The voltage between phase B and the neutral line of the feeder being
monitored by the 565/575 Relay.
A 6.7
VOLTAGE C-N
2.30 kV
The voltage between phase C and the neutral line of the feeder being
monitored by the 565/575 Relay.
The following message will be displayed if no Metering Transducer Module (MTM) has been connected. If a MTM is used and
an Option Card is installed, see METERING DATA page in Actual Values for frequency reading.
A 6.8
FREQUENCY OF
FEEDER 60.1 Hz
This is the frequency of the feeder voltage being monitored by the 565/575
Relay. The frequency measurements are also enhanced. They are accu-
rate to better than 0.1% of nominal frequency (0.05 Hz). Displayed data
resolution is now 0.01 Hz.
A 6.9
VOLTAGE
END OF PAGE
The last line of page 6, actual values. Press the PAGE key to view page 7.
ACTUAL VALUES MODE - VOLTAGE
