4-12
Location Message Line Description
A 7.1
ACTUAL VALUES
EVENT
The Actual Values page 7 header. This page allows the recorded events to
be viewed.
* NOTE: See Section 7 for more information on Event Recording.
Message A 7.2 will only appear if event recording has been disabled in setpoints.
A 7.2
EVENT RECORDING
DISABLED
This message is used to inform the user that event recording has been
disabled.
Messages A 7.3 to A 7.11 will only appear if event recording has been enabled in the setpoints mode.
A 7.3
NO. OF EVENTS:
XX
This message shows the number of recorded events.
A 7.4
VIEW EVENTS?
NO
This message asks if the user wants to view events. Use the NEXT
CHOICE key to display YES or NO and press STORE to select the choice.
If YES is selected, the event template will appear for 2 seconds. Following
this, the first event will be displayed. Viewing of Event Recorder data is in
natural order — last event is first viewed.
A 7.5
## EVENT CAUSE
t mm/dd/yy hh:mm
Event template: The top line shows the event number and the cause of
event fields. The second line shows the event type, date and time fields.
A 7.6
01 PH-A TIME O/C
T 04/19/90 22:30
This message shows an example of a trip event - Phase A Timed
Overcurrent Trip, occurred at 10:30pm on April 19, 1990. Press LINE
DOWN key to display the next event.
A 7.7
02 UNDERVOLTAGE
A 04/19/90 22:31
This message shows an example of an alarm event - Undervoltage Alarm.
A 7.8
03 AC JUMPER INS
O 04/20/90 11:15
This message shows an example of “other” event - Access Jumper
Installed.
A 7.9
04 SERIAL TRIP
O 03/17/94 11:14
This message shows an example of "other" event - Serial Trip. This
message is displayed if the breaker is closed when the 565/575 receives
the Modbus Serial Trip command. If the breaker is open when this Serial
Trip command is issued, it will be ignored.
A 7.10
05 SERIAL CLOSE
O 03/17/94 11:15
This message shows an example of "other" event - Serial Close, if the
breaker is open when the 565/575 receives the Modbus Serial Close
command. If the breaker does not close successfully within the breaker
discrepancy delay time, a breaker discrepancy will be declared. If the
breaker is closed when this Serial Close command is issued, it will be
ignored.
In order to prevent conflicts with the Remote Trip/Close commands via
hardware, the communication commands will only function if the Remote/
Local switch at terminals #39 and #40 is in the "open" Local position.
A 7.11
PRINT EVENTS?
NO
After all the events are viewed, pressing LINE DOWN key will show this
message, which asks users if event printout is desired. Press NEXT
CHOICE key to toggle YES or NO options and press STORE key to select
it. (NOTE: Printer is presumably connected to the rear RS232 port). Press
ACTUAL VALUES MODE - EVENT
