5-30
Location Message Line Description
CONDITION
OUTPUT
AUX. 2 RELAY
FACEPLATE
AUX. 2 LED
MODBUS READ EXCEPTION
STATUS
NO TRIP DE-ENERGIZED OFF 00H
TRIPPED
(Current > P/U)
PULSES ON 22H
TRIPPED
(Current < P/U)
DE-ENERGIZED FLASHING 02H
KEYPAD RESET DE-ENERGIZED OFF 00H
CONDITION
OUTPUT
AUX. 2 RELAY
FACEPLATE
AUX. 2 LED
MODBUS READ EXCEPTION
STATUS
NO ALARM DE-ENERGIZED OFF 00H
ALARM
(Current > Alarm Level)
PULSES ON 20H
ALARM
(Current < Alarm Level)
DE-ENERGIZED OFF 00H
KEYPAD RESET DE-ENERGIZED OFF 00H
Latched
If latched operation is chosen for the Aux 2 relay, it will energize when a trip
occurs. Pressing the RESET key on the front panel will unlatch the Aux 2
relay only if the fault current is below pick up. This may be convenient if the
relay is being used to annunciate a fault condition.
CONDITION
OUTPUT
AUX. 2 RELAY
FACEPLATE
AUX. 2 LED
MODBUS READ EXCEPTION
STATUS
NO TRIP DE-ENERGIZED OFF 00H
TRIPPED
(Current > Trip Level)
ENERGIZED ON 22H
TRIPPED
(Current < Trip Level)
ENERGIZED ON 22H
KEYPAD RESET DE-ENERGIZED OFF 00H
CONDITION
OUTPUT
AUX. 2 RELAY
FACEPLATE
AUX. 2 LED
MODBUS READ EXCEPTION
STATUS
NO ALARM DE-ENERGIZED OFF 00H
ALARM
(Current > Alarm Level)
ENERGIZED ON 20H
ALARM
(Current < Alarm Level)
ENERGIZED ON 20H
KEYPAD RESET DE-ENERGIZED OFF 00H
Unlatched
If unlatched operation is selected, the Aux 2 relay becomes energized
upon declaration of a fault condition. When current drops below pick up,
the relay will de-energize.
L
A
SETPOINTS MODE - CONFIGURATION
