5-31
Location Message Line Description
CONDITION
OUTPUT AUX. 1
RELAY
FACEPLATE
AUX. 1 LED
MODBUS READ EXCEPTION
STATUS
NO TRIP DE-ENERGIZED OFF 00H
TRIPPED
(Current > Trip Level)
ENERGIZED ON 22H
TRIPPED
(Current < Trip Level)
DE-ENERGIZED FLASHING 02H
KEYPAD RESET DE-ENERGIZED OFF 00H
CONDITION
OUTPUT AUX. 1
RELAY
FACEPLATE
AUX. 1 LED
MODBUS READ EXCEPTION
STATUS
NO ALARM DE-ENERGIZED OFF 00H
ALARM
(Current > Alarm Level)
ENERGIZED ON 20H
ALARM
(Current < Alarm Level)
DE-ENERGIZED OFF 00H
KEYPAD RESET DE-ENERGIZED OFF 00H
Message S4.34 will only appear if pulsed operation is assigned to the Aux 2 relay.
S 4.35
AUX2 RELAY PULSE
TIME 0.6 SEC
This message allows the user to set the length of the pulse for the Aux 2
relay when selected for pulse operation. The pulse time controls the
minimum length of time that the relay will be energized. The range of
values for this setpoint is 0.1 to 0.6 seconds in steps of 0.1 seconds.
Note: The Auxiliary 3 relay is failsafe and designed to operate in an
unlatched mode only. It is not programmable.
CONDITION
OUTPUT
AUX. 3 RELAY
FACEPLATE
AUX. 3 LED
MODBUS READ EXCEPTION
STATUS
NO ALARM ENERGIZED OFF 00H
ALARM
(Open Trip Coil)
DE-ENERGIZED ON 10H
ALARM
(Closed Trip Coil)
ENERGIZED OFF 00H
KEYPAD RESET ENERGIZED OFF 00H
S 4.36
BREAKER RESPONSE
DELAY 1 mS
This setpoint allows the user to enter the actual delay between the time
when the trip contact closure is sent to the breaker and the opening of the
breaker contacts. After the time delay specified, the 565/575 will begin to
accumulate the KA
2
value of the breaker interruption. Determine this
quantity from the breaker manufacturer’s data of breaker opening time.
The range of values which may be entered is 1 to 167 mS.
S 4.37
BREAKER DISCREP.
DISABLED
This message asks if you want the Breaker Discrepancy Alarm ENABLED
or DISABLED (Aux4). This feature monitors the 52a and 52b breaker
auxiliary contact and gives an alarm indication in two possible situations:
a) The TRIP relay was activated but the breaker remained closed.
(565)
SETPOINTS MODE - CONFIGURATION
