NX-8V2 Control 21
L 42 GO TO PROGRAM CODE 6............. numerical
Location 42 contains the "Go To Program Code". This location contains either a 4 or 6-digit code. If the 6-digit code option is enabled
in Location 41, THIS CODE MUST CONTAIN SIX (6) DIGITS. If this option is not enabled in location 41, the last 2 segments (digits)
will be ignored. With the NX-8V2 disarmed, the "Go To Program Code" can be used to enter the Program Mode.
43 GO TO PROGRAM CODE PARTITION & AUTHORIZATION 2............. feature select
The "Go To Program Code" can be used as a standard arm/disarm code. When using the code to arm or disarm, the user ID is 255.
(This code may not be changed in the Run Mode.)
Segment 1:
1 = Reserved.
2 = On enables "Go To Program Code" as an arm only code.
3 = On enables "Go To Program Code" as an arm only after closing.
4 = On enables "Go To Program Code" as a master arm/disarm code (can change user codes)
5 = On enables "Go To Program Code" as an arm/disarm code.
6 = On enables "Go To Program Code" to bypass zones.
7 = On enables "Go To Program Code" opening and closing reports.
8 = Reserved.
Segment 2:
1 = On enables the "Go To Program Code" for Partition #1.
2 = On enables the "Go To Program Code" for Partition #2.
3 = On enables the "Go To Program Code" for Partition #3.
4 = On enables the "Go To Program Code" for Partition #4.
5 = On enables the "Go To Program Code" for Partition #5.
6 = On enables the "Go To Program Code" for Partition #6.
7 = On enables the "Go To Program Code" for Partition #7.
8 = On enables the "Go To Program Code" for Partition #8.
L 44 DURESS CODE 6.............numerical
Location 44 contains the "Duress" code. This Location contains either 4 or 6 digits. If the 6-digit code option is enabled in Location 41,
THIS CODE MUST CONTAIN SIX (6) DIGITS. If the 6-digit option is not enabled in location 41, the last 2 digits will be ignored. If the
duress code is programmed, it will work for all partitions.
45 AUXILIARY OUTPUT 1-4 PARTITION SELECTION 4............. feature select
Location 45 is used to select which partition(s) the events must occur in before the output will activate. Location 45 has 4 segments.
Segment 1 corresponds to output 1, and Segment 4 corresponds to output 4.
Segment 1 (Aux 1) Segment 2 (Aux 2) Segment 3 (Aux 3) Segment 4 (Aux 4)
1= Partition 1 1= Partition 1 1= Partition 1 1= Partition 1
2= Partition 2 2= Partition 2 2= Partition 2 2= Partition 2
3= Partition 3 3= Partition 3 3= Partition 3 3= Partition 3
4= Partition 4 4= Partition 4 4= Partition 4 4= Partition 4
5= Partition 5 5= Partition 5 5= Partition 5 5= Partition 5
6= Partition 6 6= Partition 6 6= Partition 6 6= Partition 6
7= Partition 7 7= Partition 7 7= Partition 7 7= Partition 7
8= Partition 8 8= Partition 8 8= Partition 8 8= Partition 8
46 AUXILIARY OUTPUT 1 - 4 SPECIAL TIMING 4............. feature select
Location 46 contains special timing feature activation for the four auxiliary outputs. Segment 1 corresponds to output 1; Segment 4
corresponds to output 4.
Segments 1 - 4:
1 = On if output should be timed in minutes; Off if timed in seconds.
2 = On if output should latch; Off if output should be timed.
3 = On if output should stop timing upon code entry; Off if the output should continue to time upon code entry.
4 = On if output should only activate between the closing and opening time in loc. 52 and 53.
5 = On if output should only activate between the opening and closing time in loc. 52 and 53.
6 = On if output should be inverted (0 volts going to 12 volts when activated).
7 = Reserved.
8 = Reserved.
47 AUXILIARY OUTPUT 1, EVENT & TIME 2............. numerical
Segment 1: Use Table XIII-1 to select the event that will activate Auxiliary Output 1.
Segment 2: Program the timing from 0-255 (minutes or seconds, depending on data programmed in Segment 1, Location 46).
Programming a "0" makes the output follow the event.
