Function Default setting Required setting
Call waiting Off On if reporting to
central station and
customer has call
waiting service
Exit extension On On
Swinger shutdown On (one trip) On (one trip)
Fire alarm verify Off On
Duress/panic code Disabled Disabled
Cross zone Disabled Disabled for zones with
high probability of false
alarms
Table 9 below describes nonprogrammable (hard-coded)
system operation, as required to meet ANSI-SIA CP-01.
Table 9: Nonprogrammable system operation
Function Operation
Silent exit All annunciators enabled
Remote arming exit time and
progress annunciation
All annunciators enabled
Abort annunciation Enabled
Cancel report annunciation Enabled
Recent closing Enabled (2-minute window)
Exit error Enabled
Restoration of power Panel resumes operation in same
arming state and disregards alarm
signals from sensors for the first 60
seconds after power restoration
Cancel alarm Enter code only
Central station reporting
The panel has been tested with the following central station
receivers using SIA and Contact ID reporting formats:
Note: Before beginning installation, installers must verify
compatibility with the following central station receivers.
• Radionics D6600 central station receiver
• Sur-Gard central station receiver with models SG-
DRL2A and SG-CPM2
• CS5000 digital alarm communicator receiver
UL Canada listed installations
This section describes the requirements for CUL (UL
Canada) listed installations.
Canadian standards CSA certified accessories:
• Standard Class 2, 9 VAC, 3.34 A power transformer (GE
Security model 22-153-CN).
Residential burglary alarm system unit (ORD-C1023-1974):
basic system as described for UL 1023 listed installations
plus:
• Hardwired magnetic contact (13-068 or 13-071) or
wireless learn mode door/window sensor (60-670)
• Siren timeout set to six minutes or more
Residential fire warning system control unit (ULC-S545-
M89): basic system as described for UL 985 listed
installations plus:
• Wireless smoke sensor 60-848-02-95, TX-6010-01-1
learned into sensor group 26
• Siren timeout set to six minutes or more
• For 24-hour backup, the total current draw for all
connected devices is limited to 250 mA (during normal
standby conditions) using a 1.2 AH battery.
FCC compliance
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a residential environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Part 15 registration number: B4Z-910C-SIMON
Part 68. This equipment complies with Part 68 of the FCC
rules and the requirements adopted by ACTA.
FCC registration number: US: B4ZAK02B55910
8 Simon XT V2 Installation Guide
