GE 469

122 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
F146
Unsigned
16 bit integer
ANALOG IN DIFFERENTIAL LOGIC
0 1>2 (or 3>4)
1 2>1 (or 4>3)
2 1<>2 (or 3<>4)
F147
Unsigned
16 bit integer
ANALOG IN DIFFERENTIAL ACTIVE
WHEN
0Always
1f Start/Run
F148
Unsigned
16 bit integer
TORQUE DISPLAY UNITS
0Newton-meter
1Foot-pound
F149
Unsigned
16 bit integer
UNDERVOLTAGE TRIP MODE
01-Phase
13-Phase
F150
Unsigned
32 bit integer
IP ADDRESS
IP address, subnet mask or default gateway. Each byte
in this register represents one octet of an IP address.
For example: 0x015EDA1F represents address
1.94.218.31
F151
Unsigned
16 bit integer
DEVICENET CONNECTION STATUS
0Nonexistent
1Configuring
2--
3 Established
4Time Out
5 Deferred Date
F152
Unsigned
16 bit integer
ETHERNET STATUS
BIT 0 Diagnostic
BIT 1 Connection Status
BIT 2 Not Used
BIT 3 Ethernet Link Status
F153
Unsigned
16 bit integer
DEVICENET PORT STATUS
0Not Powered
1Port Operational
2
Internal Configuration Error - Data
Size Larger Than Confirmed
3 Unrecoverable Fault
4Minor Fault
F154
Unsigned
16 bit integer
DEVICENET LINK STATUS
0Not Online, Not Powered
1 Online, Connected
2--
3 Online, Not Connected
4 Critical Link Failure
5 Connection Timeout
Table 8: Data Formats (Sheet 14 of 15)
CODE TYPE DEFINITION
