Acknowledge Handler Object (class code 2Bh)
The class and instance attributes for the acknowledge handler object (class 2Bh) are as
follows:
0Eh
Produced connection path: Application
object producing data on the
connection.
Get_Attribute_Single
20 04 24 64 30 03,
N/A, N/A
Array of
USINT
0Fh
Consumed connection path length.
Number of bytes in the
consumed_connection_path length
attribute
Get_Attribute_Single 6, 6, 6 UINT
10h
Consumed connection path. Specifies
the application object(s) to receive the
data consumed by this connection
object.
Get_Attribute_Single
20 04 24 64 30 03,
N/A, N/A
Array of
UINT
11h
Production inhibit time. Defines the
minimum time between new data
production.
Get_Attribute_Single 0, 0, 0 UINT
Table 21: Connection Object, Class code 05h, Instance 02h (Polled I/O connection), Attributes:
Attribute Name/Description Services Default, Min, Max Data type
Table 22: Acknowledge handler object, Class code 2Bh, Attributes:
Attibute Name/Description Services Default, Min, Max Data type
01h
Revision of the acknowledge
handler object.
Get_Attribute_All 1, 1, 1 UINT
02h
Maximum instance created by
this object
Get_Attribute_Single UINT
