GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 25
01DE User map address #95 0 3FFF 1 hex F1 000
01DF User map address #96 0 3FFF 1 hex F1 000
01E0 User map address #97 0 3FFF 1 hex F1 000
01E1 User map address #98 0 3FFF 1 hex F1 000
01E2 User map address #99 0 3FFF 1 hex F1 000
01E3 User map address #100 0 3FFF 1 hex F1 000
01E4 User map address #101 0 3FFF 1 hex F1 000
01E5 User map address #102 0 3FFF 1 hex F1 000
01E6 User map address #103 0 3FFF 1 hex F1 000
01E7 User map address #104 0 3FFF 1 hex F1 000
01E8 User map address #105 0 3FFF 1 hex F1 000
01E9 User map address #106 0 3FFF 1 hex F1 000
01EA User map address #107 0 3FFF 1 hex F1 000
01EB User map address #108 0 3FFF 1 hex F1 000
01EC User map address #109 0 3FFF 1 hex F1 000
01ED User map address #110 0 3FFF 1 hex F1 000
01EE User map address #111 0 3FFF 1 hex F1 000
01EF User map address #112 0 3FFF 1 hex F1 000
01F0 User map address #113 0 3FFF 1 hex F1 000
01F1 User map address #114 0 3FFF 1 hex F1 000
01F2 User map address #115 0 3FFF 1 hex F1 000
01F3 User map address #116 0 3FFF 1 hex F1 000
01F4 User map address #117 0 3FFF 1 hex F1 000
01F5 User map address #118 0 3FFF 1 hex F1 000
01F6 User map address #119 0 3FFF 1 hex F1 000
01F7 User map address #120 0 3FFF 1 hex F1 000
01F8 User map address #121 0 3FFF 1 hex F1 000
01F9 User map address #122 0 3FFF 1 hex F1 000
01FA User map address #123 0 3FFF 1 hex F1 000
01FB User map address #124 0 3FFF 1 hex F1 000
01FC User Map Address #125 0 3FFF 1 hex F1 000
01FD Reserved
01FE Reserved
01FF Reserved
Actual Values (Addresses 0200 to 0FFF)
MOTOR
STATUS
0200 Motor status 0 4 1 -- F133 0
0201 Motor thermal capacity used 0 100 1 % F1 0
0202 Estimated time to trip on overload –1 99999 1 s F20 –1
0204Motor speed 011--F1350
0205 Communication setpoint access 0 1 ----F126--
0206 Reserved
0207 Reserved
Table 7: 469 MEMORY MAP (Sheet 7 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
