GE 489 Communications Guide

40 489 GENERATOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
2C93 Analog Input 3 Alarm Events 0 to 1 1 – F105 0
2C94 Analog Input 3 Trip 0 to 2 1 – F115 0
2C95 Assign Trip Relays (1-4) 0 to 3 1 – F50 1
2C96 Analog Input 3 Trip Level –50000 to 50000 1 Units F12 20
2C98 Analog Input 3 Trip Pickup 0 to 1 1 – F130 0
2C99 Analog Input 3 Trip Delay 1 to 3000 1 s F2 1
2C9A Analog Input 3 Name 0 to 12 1 – F22 _
ANALOG INPUT/OUTPUT / ANALOG INPUT 4
2CC0 Analog Input 4 0 to 3 1 – F129 0
2CC5 Analog Input 4 Units 0 to 6 1 – F22 _
2CC8 Analog Input 4 Minimum –50000 to 50000 1 Units F12 0
2CCA Analog Input 4 Maximum –50000 to 50000 1 Units F12 100
2CCC Block Analog Input 4 From Online 0 to 5000 1 s F1 0
2CCD Analog Input 4 Alarm 0 to 2 1 – F115 0
2CCE Assign Alarm Relays (2-5) 1 to 4 1 – F50 16
2CCF Analog Input 4 Alarm Level –50000 to 50000 1 Units F12 10
2CD1 Analog Input 4 Alarm Pickup 0 to 1 1 – F130 0
2CD2 Analog Input 4 Alarm Delay 1 to 3000 1 s F2 1
2CD3 Analog Input 4 Alarm Events 0 to 1 1 – F105 0
2CD4 Analog Input 4 Trip 0 to 2 1 – F115 0
2CD5 Assign Trip Relays (1-4) 0 to 3 1 – F50 1
2CD6 Analog Input 4 Trip Level –50000 to 50000 1 Units F12 20
2CD8 Analog Input 4 Trip Pickup 0 to 1 1 – F130 0
2CD9 Analog Input 4 Trip Delay 1 to 3000 1 s F2 1
2CDA Analog Input 4 Name 0 to 12 1 – F22 _
489 TESTING / SIMULATION MODE
2D00 Simulation Mode 0 to 3 1 – F138 0
2D01 Pre-fault To Fault Time Delay 0 to 300 1 s F1 15
489 TESTING / PRE-FAULT SETUP
2D20 Pre-Fault Iphase Output 0 to 2000 1 × CT F3 0
2D21 Pre-Fault Voltages Phase-N 0 to 150 1 × Rated F3 100
2D22 Pre-Fault Current Lags Voltage 0 to 359 1 ° F1 0
2D23 Pre-Fault Iphase Neutral 0 to 2000 1 × CT F3 0
2D24 Pre-Fault Current Ground 0 to 2000 1 × CT F3 0
2D25 Pre-Fault Voltage Neutral 0 to 1000 1 Volts F2 0
2D26 Pre-Fault Stator RTD Temp –50 to 250 1 °C F4 40
2D27 Pre-Fault Bearing RTD Temp –50 to 250 1 °C F4 40
2D28 Pre-Fault Other RTD Temp –50 to 250 1 °C F4 40
2D29 Pre-Fault Ambient RTD Temp –50 to 250 1 °C F4 40
2D2A Pre-Fault System Frequency 50 to 900 1 Hz F2 600
2D2B Pre-Fault Analog Input 1 0 to 100 1 % F1 0
2D2C Pre-Fault Analog Input 2 0 to 100 1 % F1 0
2D2D Pre-Fault Analog Input 3 0 to 100 1 % F1 0
2D2E Pre-Fault Analog Input 4 0 to 100 1 % F1 0
2D4C Pre-Fault Stator RTD Temp –50 to 250 1 °F F4 40
2D4D Pre-Fault Bearing RTD Temp –50 to 250 1 °F F4 40
2D4E Pre-Fault Other RTD Temp –50 to 250 1 °F F4 40
2D4F Pre-Fault Ambient RTD Temp –50 to 250 1 °F F4 40
489 TESTING / FAULT SETUP
2D80 Fault Iphase Output 0 to 2000 1 × CT F3 0
2D81 Fault Voltages Phase-N 0 to 150 1 × Rated F3 100
2D82 Fault Current Lags Voltage 0 to 359 1 ° F1 0
2D83 Fault Iphase Neutral 0 to 2000 1 × CT F3 0
Table CG–1: 489 Memory Map (Sheet 28 of 30)
ADDR Name RANGE STEP UNITS FORMAT DEFAULT
1, 2, 3 See Table footnotes on page page 42
