GE 489 Communications Guide

489 GENERATOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 45
F107
Unsigned
16 bit integer
NOMINAL FREQUENCY
0 ----
1 60 Hz
2 50 Hz
3 25 Hz
F109
Unsigned
16 bit integer
STARTER STATUS SWITCH
0Auxiliary A
1Auxiliary B
F115
Unsigned
16 bit integer
ALARM / TRIP TYPE SELECTION
0Off
1Latched
2Unlatched
F117
Unsigned
16 bit integer
RESET MODE
0All Resets
1Remote Reset Only
2Keypad Reset Only
F118
Unsigned
16 bit integer
SETPOINT GROUP
0Group 1
1Group 2
F120
Unsigned
16 bit integer
RTD TYPE
0 100 Ohm Platinum
1 120 Ohm Nickel
2 100 Ohm Nickel
3 10 Ohm Copper
F121
Unsigned
16 bit integer
RTD APPLICATION
0None
1Stator
2Bearing
3Ambient
4Other
F122
Unsigned
16 bit integer
RTD VOTING SELECTION
1RTD #1
2RTD #2
3RTD #3
4RTD #4
5RTD #5
6RTD #6
7RTD #7
8RTD #8
9RTD #9
10 RTD #10
11 RTD #11
12 RTD #12
Table CG–2: Data Formats (Sheet 4 of 14)
CODE TYPE DEFINITION
